2. Remove the reducer piece (11).
3. Remove the adaptor for external
dust extraction (12):
• Press against the adaptor for
external dust extraction inside
the recess in the base plate (13).
• Pull the adaptor for external
dust extraction to the rear.
Attaching and removing the
splinter guard
Attaching the splinter guard
1. Push the splinter guard (18) from
the bottom into the recess in the
baseplate (13).
Removing the splinter guard
1. Press the splinter guard (18) away
from the recess in the baseplate
(13).
Checking the battery
charge level
LEDs
red, orange, green Battery charged
red, orange
red
At the tool
1. The charge level indicator on the
tool (3) lights up during operation.
The LEDs of the charge level in-
dicator show how much charge re-
mains in the battery.
2. Charge the battery (29) when only
the red LED on the charge level in-
dicator (3) is illuminated.
At the battery
1. Press the button (32) next to the
charge level indicator button (30)
on the battery (29).
The LEDs of the charge level in-
dicator show how much charge re-
mains in the battery.
36
Meaning
Battery partially
charged
Battery needs to
be charged
2. Charge the battery (29) when only
the red LED on the charge level in-
dicator (30) is illuminated.

Charging the battery

See also the charger instruction
manual.
Notes
• If warm, allow the battery to cool
before charging.
• Do not expose the battery to dir-
ect sunlight for long periods and
do not place it on a radiator (max.
50°C).
Charging the battery
1. Remove the battery (29) from the
device.
2. Push the battery (29) into the char-
ging slot of the battery charger
(28).
3. Connect the battery charger (28) to
a power outlet.
4. After charging, disconnect the bat-
tery charger (28) from the mains.
5. Pull the battery (29) out of the bat-
tery charger (28).
Control LEDs on the charger (28):
green red
lights up —
— lights up Battery is char-
— flashes
flashes flashes
Meaning
• Battery is fully
charged
• stand-by (No
battery inser-
ted)
ging
Battery is over-
heated
Battery is defect-
ive
