GB MT
23 Switch (dust blower function)
24 Lever
25 Wood saw blade, Clean cut
edges, Curved cut
26 Wood saw blade, Clean cut
edges
27 Parallel guide
28 Charger (not included)
29 Battery (not included)
30 Charge level indicator
31 Battery release
32 Button (Charge level indicator)
33 Storage case

Description of functions

With the jigsaw, the saw blade
clamped on one side cuts via a
stroke movement. With the pendulum
stroke, the guide roller moves the saw
blade forwards during every upstroke
in addition to the vertical saw move-
ment.
Please refer to the descriptions below
for information on how the operating
elements work.

Technical data

Cordless Jigsaw 20V
............................... PPSTDA 20-Li A1
Rated voltage U ...................... 20 V ⎓
Weight with battery
(Smart PAPS 204 A1) ..............≈2.3 kg
Idle stroke rate ........... 800–3800 min⁻¹
Stroke length ........................... 26 mm
Cutting depth
– wood ............................... ≤ 155 mm
– non-ferrous metal .............. ≤ 20 mm
– mild steel ........................... ≤ 10 mm
Bevel cutting
................. −45°; −22.5°; 0°; 22.5°; 45°
Sound pressure level (L
...............................87.6 dB; K
28
)
pA
=5 dB
pA
Sound power level (L
– Measured .......... 95.6 dB; K
Vibration (a ), wood
h
– Handle ........ 4.420 m/s²; K=1.5 m/s²
– Auxiliary handle
....................... 5.621 m/s²; K=1.5 m/s²
Vibration (a ), metal
h
– Handle ........ 4.275 m/s²; K=1.5 m/s²
– Auxiliary handle
....................... 6.591 m/s²; K=1.5 m/s²
Temperature ............................ ≤50 °C
– Charging ............................. 4–40 °C
– Operation ........................−20–50 °C
– Storage ............................... 0–45 °C
PARKSIDE Performance Smart
battery Smart PAPS 204 A1/
Smart PAPS 208 A1/
Smart PAPS 2012 A1
– frequency band 2400 – 2483.5 MHz
– transmitted power ............≤ 20 dBm
CAUTION! Hearing damage! Wear
ear protection.
Levels of noise and vibration were de-
termined according to the standards
and regulations in the declaration of
conformity.
The specified total vibration value and
the stated noise emission value have
been measured according to a stand-
ardised test method and can be used
to compare one power tool with an-
other. The specified total vibration
value and the stated specified noise
emission value can also be used for a
provisional assessment of the load.
WARNING! The vibration and
noise emissions may deviate from
the specified values during actual
use of the power tool, depending on
how the power tool is being used. Try
to keep the exposure to vibrations
as low as possible. An example of a
measure to reduce vibration expos-
ure is limiting the working hours. All
)
WA
=5 dB
WA
