Storage / parking position for high-pressure gun
10
Transport handle, extendable
11
Power Control spray lance Dirt grinder for stubborn
12
contamination, pressure stage: HARD
Power Control spray lance Vario Power for the most
13
common cleaning tasks, pressure stages: HARD /
MEDIUM / SOFT / MIX
Power Control high-pressure gun
14
Button for separating the high-pressure hose from
15
the high-pressure gun
High-pressure gun lever
16
Pressure indicator (0-MIX / 1-SOFT / 2-MEDIUM /
17
3-HARD)
High-pressure gun lock
18
Carrying handle
19
Hose switch
20
High pressure hose reel
21
Crank handle for hose reel
22
Type plate
23
Accessory compartment
24
Hook for net attachment
25
Mesh for accessory compartment
26
Mains connection cable with mains plug
27
Coupling for the water connection
28
*Garden hose (fabric reinforced, diameter at least
29
1/2 inch (13 mm), length at least 7.5 m, with com-
mercially available quick coupling)
*KÄRCHER suction hose for water supply from
30
open containers (order no. 2.643-100)
Included screws and dowels
31
* additionally required
Supplied screws and dowels
Illustration C
Stand dowels (2 pieces)
1
Screw M 4x20 (2 pieces)
2
Screw M 4x22 (2 pieces)
3
Screw M 4x16 (8 pieces)
4
Installation
For the illustrations, refer to the graphics page.
Fit the supplied loose parts onto the device before start-
ing up the device.
Have the included screws and the appropriate screw-
driver ready.
Fitting the wheels
1. Insert the wheels.
Note
Pay attention to the alignment of the hole.
Illustration D
2. Secure the wheels with 1 screw each.
Mounting the stand
1. Insert the stand.
Illustration E
2. Insert the 2 dowels into the holes as far as they will
go.
3. Secure the base with 2 screws.
Mounting the storage for spray lances
1. Hook in the storage for the spray lances.
2. Secure the storage with 2 screws.
Illustration F
3. Secure the cover with 4 screws.
Illustration G
Mounting the transport handle
1. Attach the transport handle.
Illustration H
Mounting the accessory net
1. Hang the accessory net on the hooks.
Illustration I
Push the high-pressure hose through the
1. Insert the high-pressure hose through the hose
guide from the rear.
Illustration J
Installing the water connection coupling
1. Screw the water connection coupling onto the water
connection on the device.
Illustration K
1. Place the device on a level surface.
2. Completely unwind the high-pressure.
3. Pull the high-pressure hose completely forward
through the hose guide and eliminate any loops and
twists.
4. Insert the high-pressure hose into the high-pressure
gun until it audibly clicks into place.
Note
Take care to ensure the correct alignment of the nipple.
Illustration L
5. Check the secure connection by pulling on the high-
pressure hose.
6. Plug the mains plug into a mains socket.
For the connection values, see the type plate or chapter
Technical data.
Observe the water distribution company regulations.
ATTENTION
Damage through contaminated water
Contamination in the water can damage the pump and
the accessories.
KÄRCHER recommends using the KÄRCHER water fil-
ter for protection(special accessory, order number
4.730-059).
Connection to the water line
ATTENTION
Risk of damage when using hose couplings made
of brass with AquaStop function from third-party
suppliers.
Damage to the high-pressure pump.
Only use hose couplings with/without AquaStop func-
tion from Kärcher, hose couplings without AquaStop
function or hose couplings made of plastic with AquaS-
top function from third-party suppliers.
1. Plug the garden hose onto the water connection
coupling.
2. Connect the garden hose to the water line.
English
hose guide
Initial startup
Water supply
