Série R290 M-Thermon HT
Appliqué à
Capteur de température de décharge Tp
R90℃=5KΩ±3%，B25/50=3950K±3%
Temp. (°C)
Rmax
-40 2002,628
-39 1881,964
-38 1769,292
-37 1664,009
-36
1565,57
-35 1473,481
-34 1387,282
-33 1306,554
-32 1230,918
-31 1160,015
-30
1093,521
-29 1031,137
-28 972,588
-27 917,615
-26 865,981
-25 817,469
-24
771,875
-23 729,009
-22 688,698
-21 650,778
-20 615,097
-19 581,515
-18
549,899
-17 520,129
-16 492,089
-15 465,672
-14 440,779
-13 417,316
-12
395,197
-11 374,34
-10 354,669
-9 336,113
156
Résistance (kΩ)
R (t) Normal Rmin
1642,059 1281,49
1544,968 1207,972
1454,213 1139,134
1369,32 1074,631
1289,862 1014,154
1215,451 957,421
1145,725 904,168
1080,355 854,156
1019,042 807,166
961,505 762,994
907,487 721,452
856,752 682,368
809,086 645,583
764,281 610,947
722,152 578,323
682,528 547,586
645,245 518,616
610,156 491,303
577,121 465,544
546,012 441,246
516,708 418,318
489,096 396,678
463,073 376,247
438,542 356,955
415,411 338,733
393,595 321,518
373,014 305,25
353,595 289,874
335,268 275,339
317,967 261,594
301,632 248,595
286,206 236,298
Temp. (°C)
Rmax
-8 318,604
-7 302,08
-6 286,483
-5 271,757
-4
257,852
-3 244,717
-2 232,309
-1 220,585
0 209,504
1 199,029
2
189,125
3 179,759
4 170,899
5 162,517
6 154,585
7 147,077
8
139,97
9 133,239
10 126,864
11 120,825
12 115,103
13 109,679
14
104,537
15 99,662
16 95,038
17 90,652
18 86,489
19 82,539
20
78,789
21 75,228
22 71,846
23 68,633
Résistance (kΩ)
R (t) Normal Rmin
271,634 224,664
257,867 213,653
244,857 203,232
232,561 193,365
220,937 184,022
209,945 175,173
199,55 166,79
189,716 158,848
180,412 151,321
171,607 144,186
163,273 137,422
155,383 131,007
147,911 124,923
140,835 119,152
134,13 113,675
127,778 108,478
121,757 103,544
116,049 98,859
110,638 94,411
105,505 90,185
100,636 86,17
96,017 82,354
91,633 78,728
87,471 75,28
83,52 72,001
79,767 68,882
76,202 65,915
72,815 63,091
69,596 60,404
66,537 57,845
63,627 55,409
60,86 53,088
Continuer sur la page suivante...
