Operating instructions
for
pro's pro® PHOENIX-2

TROUBLESHOOTING

Maintenance

•
The Pro's Pro Phoenix stringing machine is supplied correctly adjusted and calibrated. It has been developed to enable simple and
maintenance-free operation.
•
Always place the machine in a clean and safe place and keep it away from dust, grease, moisture and heat.
•
Clean the stringing machine frequently to prevent the accumulation of dust and dirt. Clean the surface of the machine with a soft
cloth or brush it to remove dust from the quick-release clamp, for example.
•
Do not clean the plastic with cleaning agents (such as benzene or similar agents) that can damage the plastic.
•
Use isopropyl alcohol and a soft, clean cloth to clean the holding clamps, the rails, the quick release and the inside of the lower parts
of the clamps.
•
Use a fine emery cloth to remove any string residue from the retaining clamps and the quick release. - However, do not use sandpaper
•
Use a light machine oil, such as sewing machine oil, to lubricate the extension of the holding clamps and the inside of the holder on the
lower parts of the clamps
•
Do not lubricate the rails of the turntable!
•
Do not use penetrating oil to clean or lubricate.
•
Check the pliers / pliers bases of the Pro's Pro Phoenix often to make sure they are holding the string properly.
•
After tensioning, set the weight back to 0 kg to relieve the spring.
Troubleshooting
The holding clamp fixes the string
not
The string glides through the quick
release
The holding clamp cannot be
moved smoothly
The lower part of the pliers can be
Do not fix
The pull weight is not correct

Adjusting the lower parts of the pliers

If you do not fix the base to the rail, it must be adjusted. To do this, proceed as
follows:
.
1) Clean the teeth of the holding pliers.
2) When open, turn the wheel of the holding clamp to reduce the distance
1) Use a fine emery cloth to remove string residue from the retaining clamps and the quick
release - but do not use sandpaper. (if necessary, you can also use a glue remover)
2) Reduce the distance in the quick release by turning the quick release adjustment screw
to the left until the string is held securely.
Clean the extension of the holding clamp, the inside of the holder on the lower part of the clamp and
the rails on the turntable.
Lubricate the extension of the holding clamp and inside the holder on the
The lower part of the pliers after you have cleaned them.
1) Clean the rails on the turntable.
2) Adjust the lower part of the pliers according to the instructions.
Calibrate the train system
page 9 from 11
