Operating instructions
for
pro's pro® PHOENIX-2
Tool tray
Foothold
Clamp
Frame fixing pliers
Support arm
Heart head fixation
Rubber pad
Fine adjustment
screw of the support
arm
Support
Turntable
Locking screw of the
support
.
Clamping head
Locking lever for
fixing the turntable
H-foot
Quick release
Quick release
adjusting screw
Crank lock lever
Weight
adjustment screw
Clamping head Locking screw
For moving / sliding the
clamping head outside the
guide
