DELTA DORE TYMOOV Solar 5 SO Mode D'emploi page 33

4/ Starting up for the first time
4.2 Pairing an initial remote control with a motor
When switched on for the first time, the motor runs a cycle to warn that no
transmitter is associated.
The motors will automatically await association.
You have 5 minutes after power up to associate the motor to the control device.
4.2.1 Case no. 1 : a single motor is switched on
❶ The motor is waiting for pairing.
❷ On the remote control,
press and at the same time for 3 seconds,
until the red LED lights up. Release the buttons.
When the motor is detected, the LED briefly
lights up green.
❸ After a few seconds, the shutter activates
twice to confirm pairing.
The remote control is paired and the motor automatically switches to "Setting
stops" mode.
4.2.2 Case no. 2 : several motors are switched on
❶ On the remote control, press
red LED lights up. Release the buttons.
The remote control searches for the various motors.
The LED flashes red, then briefly green as soon as a new motor is found.
❷ When the LED starts flashing red slowly, press the
required to select the motor to be paired.
The corresponding shutter activates briefly, once.
❸ Once the motor has been found, briefly press
❹ After a few seconds, the shutter briefly activates twice to confirm pairing.
❺ To exit pairing mode, press
The remote control is associated and the motor automatically switches to "Set
stops" mode.
1 1 2 2
and
for 3 seconds.
1
at the same time, for 3 seconds, until the
1 1 2 2
.
2
x 2
1
2
button as many times as
1 2
1 2
EN
33
