are correctly supervised or that instructions relating to the use of the
safe use of the device have been provided to them, and provided that
they understand the risks involved.
Children must not play with the device. Cleaning and maintenance
by the user must not be performed by children if unsupervised.
- The operating device for a switch without a lock must be in direct
view of the driven part, but away from the moving parts. It must be
installed at a minimum height of 1.5 m and must not be accessible
to the public.
- Fixed control devices must be installed so as visible.
- During the use of a switch without a lock, make sure that all other
persons present keep their distance;
- Frequently check the equipment to detect any imbalances or signs
of wear or damage to cables and springs.
- Do not use the device when repairs or adjustments are required.
- TYMOOV xSO motors are motors with 868 MHz - X3D wireless
receivers. They are only compatible with remote controls from the
DELTA DORE X3D range: TYXIA 1701, TYXIA 2331 and TYXIA 1716.
- Sufficiently rigid roller shutter slats should be used.
- When the roller shutter is closed, the apron must not overlap the
runners by more than one and a half slats.
- The apron clips or automatic locks used on the shutter must be used in
accordance with their manufacturer's instructions for use.
The max. torques, with a locked rotor, for the
TYMOOV 5 SO or 10 SO motors are: 5 Nm: 7Nm / 10 Nm: 12Nm.
For the TYMOOV 15 SO motors they are: 15Nm: 18 Nm
For the TYMOOV 20 SO motors they are: 20 Nm: 24 Nm
Models that do not support these torques cannot be mounted. It is
essential that you adjust the number of locks based on the model and
the number of links.
- If used with upper stops, preferably use systems built into the
runners.
Preliminary elements
