1/ Technical Specifications
• Power supply: 12 Vcc
TYMOOV solar motors may only be used with the DELTA DORE batteries supplied with
the motors:
TYMOOV 5 SO: Battery 10S1P 1200 Ni-MH ref. 7011725 (x5), 7011738 (x20)
TYMOOV 10 SO - 15 SO: Battery 10S1P1 2200 Ni-MH ref. 6357037 (x1), 7011724 (x5) and
7011737 (x20)
TYMOOV 20 SO: 2x Battery 10S1P1 2200 Ni-MH ref. 6357037 (x1), 7011724 (x5) and
7011737 (x20) with the same date code + 1 double battery cable ref.7011771 (x5).
• Class III insulation
• Mex. operating time: 10 minutes
• Electrical power ratings:
TYMOOV 5 SO: 25 W - TYMOOV 10 SO: 40 W
TYMOOV 15 SO: 50 W - TYMOOV 20 SO: 60 W
• Radio frequency X3D: 868.7 MHz to 869.2 MHz
• Maximum wireless power < 10 mW, Category 2 receiver
• Wireless range up to 300 metres in an open field, variable depending on the associated
equipment (the range can vary depending on the installation conditions and the
electromagnetic environment)
• Max. number of associated transmitters: 16
• Weighted noise pressure level A: LpA ≤ 70 dB(A).
• Protection rating: IP44
• Operating temperature: -20°C to +60°C
• Storage temperature:
- Motor: -30°/+70°C
- Battery: -20°/+35°C
- Solar panel: -20°/+70°C
European Directive 2006/66/EC
(for battery products)
The crossed-out bin means:
The batteries should not be thrown away with household waste.
Consumers should take them to an approved recycling point at a business or distribu-
tor, or run by a local area.
Batteries contain toxic substances and heavy metals that can harm the environment and
health.
Used batteries can be recycled; they contain precious metals like iron, zinc, manganese and
nickel.
IMPORTANT: for products that take batteries: there is a risk of fire or explosion if
the original batteries are replaced by incorrect batteries (example: Alkaline >
Lithium; AA(LR6) > AAA(LR03)).
Do not discard a battery in a fire or hot oven; do not crush a battery; do not cut a battery or
it could explode.
Do not keep a battery in a very high temperature environment or subject it to extremely low
air pressure which could trigger an explosion or the release of flammable liquid or gas.
- The battery must be removed from the device before the latter is discarded;
- The battery must be disposed of safely.
