DELTA DORE TYMOOV Solar 5 SO Mode D'emploi page 26

Recommendations
- Pay attention to the frame rigidity with stop systems on the shutter
blades.
- It is essential that you connect the TYMOOV Solar motor to the
DELTA DORE solar panel and the DELTA DORE battery. Using
another panel can cause functional faults.
- TYMOOV xSO motors check the physical stops every 100
operations, so the motor automatically compensates for any apron
movement.
- Correct operation of the motor is ensured if it is installed and used
according to the following recommendations.
It is essential that peripheral components such as the rolling tube,
the supports, the screws etc. are appropriate and are assembled
in accordance with the latest standards. The specifications of
the driven part must be compatible with the assigned load and
operating time.
- Weighted noise pressure level A: LpA ≤ 70 dB(A).
- Cables passing through a metallic wall must be protected and
isolated by a sleeve.
The TYMOOV xSO cable is detachable.
- If the power cable is damaged, it must be replaced by the
manufacturer, by the aftersales service, or by similar qualified
personnel, so as to avoid any danger.
- The motor must be chosen according to the requirements of the
load bearing support. See our charts regarding the selection of the
motor according to shutter type. A plate on the motor indicates the
nominal torque and operating time.
- TYMOOV xSO tubular motors are designed to operate
intermittently (10 minutes of continuous operation). They are
electronically protected to prevent overheating.
- If an attempt is made to raise the shutter (for example: intruder
test), the motor will lower the apron. Caution, your fingers may be
caught.
26
