VLT Frequency Converters, 0.25–90 kW
6
A1/A2/A3/A4/A5/B1/B2/B3/B4/C1/C2/C3/C4
A
B
A1
190 (7.5)
60 (2.4)
A2
257 (10.1)
70 (2.8)
A3
257 (10.1)
110 (4.3)
A4
398 (15.7)
171 (6.7)
A5
402 (15.8)
215 (8.4)
B1
454 (17.8)
210 (8.3)
B2
624 (24.6)
210 (8.3)
6.1
B
X
A
X
X
6.4
0 mm (0.0 in)
A1/A2/A3/A4/A5
B1/B2/B3/B4
C1/C2/C3/C4
Danfoss A/S © 2025.02
C
100 (3.9)
4 x M5
100 (3.9)
4 x M5
4 x M5
10 (3.9)
10 (3.9)
4 x M5
4 x M5
100 (3.9)
100 (3.9)
4 x M6
200 (7.9)
4 x M6
[mm (in)]
6.2
A
B
B3
380 (14.9)
140 (5.5)
B4
495 (19.5)
200 (7.9)
C1
648 (25.5)
272 (10.7)
C2
727 (28.6)
339 (13.3)
C3
521 (20.5)
270 (10.6)
C4
631 (24.8)
330 (13.0)
6.3
C
2x
C
50 mm (2.0 in)
A2 + 130B1122
A3 + 130B1123
B3 + 130B1187
B4 + 130B1189
C3 + 130B1191
75 mm (3.0 in)
C4 + 130B1193
C
200 (7.9)
4 x M5
200 (7.9)
4 x M5
4 x M5
200 (7.9)
225 (8.9)
4 x M5
4 x M5
200 (7.9)
225 (8.9)
4 x M6
M5
2.3 Nm
(20 in-lb)
M6
3.9 Nm
(35 in-lb)
M8
9.6 Nm
(85 in-lb)
AN41701953385301-000301 / 130R1261 |
