Figure 70
Code d'identification FLOWSIC500 (explication)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
154
M A N U E L D ' U T I L I S A T I O N
8030094/AE00/V4-4/2024-12
Device type
FL5
FLOWSIC500
Nominal size adapter
Replacement meter only
X
1
DN 50 / 2"
2
DN 80 / 3"
3
DN100 / 4"
D
DN150 / 6", adapter 4"
Flange-flange dimension adapter
Replacement meter only
X
A
50 mm
B
171 mm
E
241 mm
G
300 mm
L
450 mm
Pressure rating / flange standard
1
PN16 / EN1092-1
2
Class 150 / ASME B16.5
3
PN16 / GOST 12815-80
4
PN16 / GOST 33259-2015
Mating surface
Replacement meter only
X
A
Flat face, smooth finish
B
Raised face, smooth finish
C
Form A / DIN EN 1092-1
D
Form B1 / DIN EN 1092-1
E
GOST V1 Series 2
GOST V1 Series 1
F
G
GOST VB Series 1
H
GOST VB Series 2
Connection p-sensor
X
Replacement meter only
1
Plug NPT 1/4"
2
Plug G1/4"
3
Compression fitting 1/4"
4
Compression fitting D6
Connection T-sensor
X
Replacement meter only
A
without
2xG1/2" 1x temperature pocket (left-
B
right), 1x blind plug
2xG1/2" 1x temperature pocket (right-
C
left), 1x blind plug
D
2xG1/2" 2x temperature pocket
E
2x G 1/2" plug
Material adapter/gas meter
1
Aluminum / aluminum
Material certification adapter/gas meter
A
3.1 / 3.1
Surface adapter/gas meter
1
Shot-peened / standard
Reserve
X
-
Nominal size gas meter
1
DN 50 / 2"
2
DN 80 / 3"
3
DN100 / 4"
C
DN150 / 6"
Flow direction
A
Left - right
B
Right - left
Transducer
1
Type 1: 300 kHz
Maximum flow rate
A
Qmax 65 m³/h
Qmax 100 m³/h
B
C
Qmax 160 m³/h
D
Qmax 250 m³/h
E
Qmax 400 m³/h
F
Qmax 650 m³/h
G
Qmax 1000 m³/h
16
Measuring span
1
1:50
2
1:100
3
1:160
4
1:200
5
1:320
6
1:400
7
1:406
8
1:625
9
1:250
17
Sensoric for volume correction
A
-
B
T-Sensor external
C
T-Sensor internal
p/T-Sensoren external
D
E
p/T-Sensoren internal
18
Gas temperature/ambient temperature
1
-25°C ... +60°C / -25°C ... +60°C
3
-40°C ... +70°C / -40°C ... +70°C
19
Pressure range p-Sensor
A
-
B
absolute 0.8 ... 5,2 bar
C
absolute 2.0 ... 10,0 bar
D
absolute 4.0 ... 20,0 bar
E
absolute 0.8 ... 20,0 bar
F
relative 0 ... 4.0 bar / 0 ... 58,0 PSI
G
relative 0 ... 10.0 bar / 0 ... 145.0 PSI
H
relative 0 ... 25.0 bar / 0 ... 362.6 PSI
20
Cable connection
1
2x M12 , 2x M8
3
2x M12
21
Power supply
B
External with backup battery
C
Autarkic with battery pack (5 years)
22
EX certification
1
ATEX Zone 1 / IEC-Ex Zone 1, Group IIB
2
ATEX Zone 1 / IEC-Ex Zone 1, Group IIC
3
CSA Class 1 Div 1, Group CD
I/O (Interface configurations)
23
F
Impulse LF + Status (galvanically isolated)
G
Impulse HF + Status (galvanically isolated)
H
Encoder + Impulse LF (galvanically isolated)
I
RS485 Module - battery powered (external)
J
RS485 Module - line powered (external)
K
Encoder + Impulse HF (not galvanically isolated)
L
2 x LF-Impulses (galvanically isolated)
M
RS485 Module - line powered (external) + Impulse HF
N
RS485 Module - line powered (external) + Impulse LF
24
Conformity
2
PED
3
MID, PED
4
PED, CIS
6
PED, China
7
PED, Ukraine
8
PED, India
9
PED, TR CU
A
Customized
B
Customized
C
Customized
25
Customized solution
XX
-
FLOWSIC500
