NOTICE
Be careful to avoid bending the pin on the antenna
when making the connection.
3. Insert the grounding rod into the ground.
4. Connect the grounding cable to the grounding rod and the
ground connection (5) on the device.
5. Connect the connecting cable to the fence connector on
the device (4) and the electric fence.
6. Pass the cable ties through the brackets on the back of the
device and use them to attach the device to the fence post.
7. Then check whether the cables are correctly connected to
the device and the fence, i.e. the grounding pin.
8. Switch the energiser battery and the Fence Sensor back on.
8.1
MOUNTING EXAMPLE 1
Partitioning the fence system. The benefit in this case is to facilitate localisation in the event
of a voltage drop.
2
20
INSTRUCTION MANUAL VOSS.FARMING FENCE SENSOR FS10
1
3
4
41645 - 02.2025 - V03
