6.2
EXPLANATION OF THE PRODUCT LABEL
Icon
Meaning
Disposal of electrical items
Documents the product' s compliance with EU directives
Protected against splash water and foreign bodies according to protection class
IP44
IP44
Low voltage protection
Reading the instruction manual
7
INITIAL SET-UP
7.1
INSERTING THE BATTERIES
I nfo
Required tools: Phillips-head screwdriver, size 1 (PH1)
1. Remove the four battery compartment screws (8) on the back of the device.
2. Open the battery compartment (8).
3. Insert the enclosed batteries into the battery compartment (8) to connect with the right poles.
N OTICE
Do not mix old batteries with new ones. Remove empty batteries from the device.
4. Close the battery compartment (8) again and re-tighten the screws.
I nfo
Using rechargeable batteries may shorten the service life of your device.
7.2
SWITCHING THE DEVICE ON AND OFF
1. To switch on the device, hold the magnet against the magnetic point (3) on the side of the device
for around two seconds.
You will hear an acoustic signal and the LED (1) will light up red.
The LED (1) flashes green and you will hear three acoustic signals.
The device is switched on and the LED (1) lights up green in regular intervals.
I nfo
Flashing stops after around two minutes to preserve the battery life.
2. To switch off the device, hold the magnet against the magnetic point (3) on the side of the device
for around two seconds.
You will hear an acoustic signal and the LED (1) will light up green.
The LED (1) flashes red and you will hear three acoustic signals.
The device is now switched off.
18
INSTRUCTION MANUAL VOSS.FARMING FENCE SENSOR FS10
41645 - 02.2025 - V03
