INSTRUCTION MANUAL VOSS.FARMING FENCE SENSOR FS10
Dimensions and weight
Dimensions incl. antenna (HxWxL) approx.:
Dimensions without antenna (HxWxL) approx.:
Weight incl. antenna and batteries approx.:
Weight incl. antenna, without batteries: approx.:
6
DEVICE OVERVIEW
1
5
No�
Name
1
LED
2
SMA connector for base antenna
3
Magnetic point
4
Fence connection
6.1
HOW IT WORKS
The VOSS.farming Fence Sensor FS10 measures the voltage at any point of your electric fence
system. The measured data is transmitted by radio frequency to the central interface, the
VOSS.farming Fence Manager FM10 or FM20 WiFi, where it is shown on the display. You can pair
up to six resp. twelve devices with the interface.
41645 - 02.2025 - V03
2
3
6
4
39.5 x 7.8 x 5.2 cm
15.1 x 7.8 x 5.2 cm
366.2 g
230 g
7
7
No�
Name
5
Ground connection
6
Base antenna
7
Opening for cable ties
Battery compartment for LR14 batteries
8
(2x 1.5 V)
DE
EN
FR
IT
NL
SV
ES
8
