Prepare and
clean the
lock recess
EN
44
Assembly
Caution!
Risk of injury caused by sharp edges and metal filings: Drilling and other machining operations can
create sharp edges and metal filings which may cause injury.
· Always particularly protect your eyes with suitable protective goggles.
Preparing for assembly
Caution!
Unsuitable doors impair personal protection and burglary protection: Only approved and technically
flawless doors are suitable for installing the lock.
· Before installing the lock, check that the door is properly fitted and is not warped.
· Check that the door is approved for use with the lock.
1
Create the lock recess at a suitable vertical installation position in the door leaf. Allow for an extra
30-mm depth for the cable loop.
2
Create the drill holes for the fixing screws as in line with Fig. 10 and Fig. 11, page 108.
3
Drill the holes for the lock fittings (only with the lock removed).
4
Clean the lock recess and all drill holes by blowing out or vacuuming.
Assembly
