Intended use
The mFlipLock basis panic/security/multipoint locking system is suitable for installation in tubular frame
doors, timber doors or doors with plastic profiles. It is not suitable for installation in swing doors.
The lock is suitable for door locks in security areas and escape routes according to the following stand-
ards:
· Escape route doors according to EN 179.
· Panic doors according to EN 1125.
· Fire or smoke doors according to EN 1634.
· Burglar-proof areas according to DIN 18251-2 class 5 and EN 12209 class 7.
The door must be made of sufficiently rigid material to limit bending during operation to a maximum of
5 mm in each direction. The material must ensure a tensile strength of >1.5 kN per screw.
The lock is suitable for use in fire doors (smoke doors). Observe allapplicable regulations for the approval of
safety doors.
Only install the lock in correctly functioning door systems. Observe all applicable regulations for the
complete door system.
The lock cannot be combined with electric door openers.
The lock is suitable for installation in doors with a high usage frequency and little incentive for care in
areas where the possibility of accident or misuse exists (office doors, for example).
All other types of use are regarded as being contrary to the intended purpose.
