Settings - EcoNet RETST700SYS Guide D'utilisation

Settings (con't)
Installer Checkout Basic Settings Basic Settings
68 80 80 80
Backlight Enabled?
Yes
Set Point Deadband 2º F
Zoning System Test Linearize Dampers
Resume Schedule Group 1 Away
71 72 75 71 36
Outside Temp Selection? T957_O Low Refrigerant Pressure
Internet
Temperature Offset 0.0º F
Relative Humidity Offset 0.0 %
Room Sensor Selection Internal
Home Away
Proximity Sensing? status: Setting airflow Yes
Refrigeration Cooling to
Smooth Arrival Enabled? Yes
70 85 34 65
OFF
BACK BACK BACK
Basic Settings
Backlight Enabled?
Yes
Outside Temp Selection?
Internet
BACK
Basic Settings
Backlight Enabled?
Yes
Outside Temp Selection?
Equipment
BACK
> Return to Table of Contents
More >
Zone 3
Zone 4
!
Set Point Deadband – This is the minimum difference between heating and
21
cooling set points in Auto mode. The default is 2 degrees. This setting is
61% 47% 44% 44%
configurable between 0 and 6 degrees. A 0 degree deadband means your
CFM: 840
54 system will switch between heating and cooling to maintain the specified set
Dining Room MORE
Basement UNITS point. The smaller the deadband setting the more frequently your system will
switch between heating and cooling.
Temperature Offset – This is an offset applied to the displayed room
temperature. A negative offset will cause the displayed indoor temperature to
be less than the sensed temperature. A positive offset will cause the displayed
temperature to be higher than sensed temperature.
Relative Humidity Offset – This is an offset applied to the indoor relative
humidity. A negative offset will cause the displayed relative humidity to be less
than the sensed relative humidity. A positive offset will cause the displayed
relative humidity to be higher than sensed relative humidity.
Note: You should allow the thermostat to calibrate in the conditioned space for 30 minutes before
adjusting offsets.
Room Sensor Selection – You can wire a remote 10K temperature sensor* to
the EcoNet Smart Thermostat. If a remote temperature sensor is connected,
you can choose to use the remote sensor, internal sensor on the Smart
Thermostat or an average between the two for current indoor temperature.
*Opti
mized for use with an Aprilaire 8051 indoor temperature sensor.
Proximity Sensing – Selecting 'No' will disable the motion sensor. To activate
the thermostat, you will need to tap the screen.
Smooth Arrival – The thermostat will start recovery at the optimum time
to ensure the set point is reached at the scheduled time. If a setback in
temperature is scheduled, for either cooling or heating, the set temperature
is ramped to the next scheduled set temperature 60 minutes before the next
time period.
Backlight Enabled – When the thermostat is not being used it will enter
standby mode. The default screen brightness in standby is 1%. You can turn
off the Backlight when in standby by selecting "No."
Outside Temp Selection – The selection determines where the outside
temperature that is displayed on the home screen is pulled from. Choose
between Internet and Equipment.
• Internet – Pulls temperature based on your zip code.
• Equipment – Uses the temperature sensor installed on your
outdoor condenser.
EcoNet Smart Thermostat User Guide
®
13
