Thermostat Settings - EcoNet RETST700SYS Guide D'utilisation

AC/HP Settings (con't)
AC/HP Settings
Outside Unit Selection EcoNet
Var-Speed RPM Clamp 7000
Cool/Heat Airflow Adjust None
Utility Input Enabled? No
Heat Source Both
Furnace Locked Out Above Disabled
Heat Pump Locked Out Below Disabled
Defrost With Aux Heat?
Yes
BACK

Thermostat Settings

Installer Checkout Installer Settings Basic Settings
68 80 80 80
Backlight Enabled? Yes
Zoning System Test Linearize Dampers
Resume Schedule Group 1 Away
71 72 71 75 36
Furnace AC/HP Thermostat
Outside Temp Selection?
T957_O Low Refrigerant Pressure Internet
Air Handler Defaults
Home Away
status: Setting airflow
Warning! These settings are to be used
Refrigeration
Cooling to
by a qualified HVAC contractor ONLY
85 70 65 34
OFF
BACK BACK BACK
Thermostat Settings
Thermostat Brand Rheem
Aux Heat Hold Off Time Auto
Filter Check Hour 9 am
Anticipator 0
Heat Set Point Maximum 90
Cool Set Point Minimum 52
BACK
The higher the negative The higher the positive
number the faster the system number the longer the system
will cycle off, increasing the will stay cycled on, lowering
number of times the system the number of times the
cycles off in an hour. system cycles off in an hour.
-5 -4 -3 -2 -1 0 1 2
Factory set default
and
recommended
rate of equipment
cycling.
> Return to Table of Contents
Heat Pump Locked Out Below – Selects the outside temperature below
which the Heat Pump will not operate and your system will rely exclusively on
(locked)
the furnace or auxiliary heat source. This should be determined by evaluating
the regions Heat Pump Balance point.
Aux Heat Defrost – This setting allows you to determine if you want auxiliary
heat to run if there is a call for heat while the heat pump is in defrost mode.
Note: A difference of two degrees will be enforced between the furnace and heat pump. Lockout
temperatures will be based off the outdoor temperature sensor connected to the outdoor unit and
NOT off the temperature provided under weather.
Reversing Valve – This setting is only available when a non-communicating
outdoor unit is installed with a gas furnace. 'B' type shall be used for Rheem heat
pumps. All other brands change to 'O' type.
Thermostat Status (Menu > Settings > Installer > Thermostat)
Zone 3
Zone 4
!
Go to Menu > Settings > Installer (tap and hold) > Thermostat.
21
44% 44% 61% 47%
CFM: 840
54
Dining Room
Basement UNITS
Thermostat Brand – The EcoNet Smart Thermostat will automatically
populate when the system starts up by reading the equipment's model
data card.
Aux. Heat Hold Off Time – This setting is designed to keep the auxiliary heat
off for a duration of time determined by the user. The time periods are:
• Auto: The thermostat will energize Aux Heat once the temperature has
reached 1 full degree beyond the heat set point. Also if the heating
system is not maintaining the set point using the heat pump alone.
• 1-60 min: The number of minutes the system will keep the Aux Heat
from coming on even when the space temperature goes beyond 1 degree.
Filter Check Hour – The time of day when the EcoNet Smart Thermostat will
check the air filter status.
Anticipator – Gives the user the ability to accurately control the system
from overshooting in heating mode and the lag of delivering conditioned air
in cooling mode. When set to 0 the system will use the factory default and
recommended rate of equipment cycling to maintain comfort. Increasing
3 4 5
the number will slow down the system, causing longer cycles. Reducing the
number will make the system react quicker, shortening the equipment cycle.
Temperature Limits – You can configure the thermostat so only a specific
heat and/or cool set point range is permitted.
• Heat Set Point Maximum – You will not be able to set the thermostat to a
temperature above this limit.
• Cool Set Point Minimum – You will not be able to set the thermostat to a
temperature below this limit.
EcoNet Smart Thermostat User Guide
®
31
