Charging from the wall socket
1. Mount the appropriate plug (see "Mounting the plug" on
page 29).
2. Only connect the device to a properly installed and easily acces-
sible wall socket, whose voltage corresponds to the specifica-
tions on the rating plate. The wall socket must still be easily
accessible after the device is plugged in. The 4 control LEDs 2
flash successively and will light up when the battery is fully
charged.
Charging via the Micro USB connection
WARNING!
Do not charge the device via the Micro USB connection when
another device is connected to the USB ports 4 / 5 .
1. Plug the Micro USB plug of a USB charger cable (not included in
the items supplied) into the Micro USB port 6 of the device.
2. Connect the USB A plug of the USB charger cable with a USB
power unit (5 V, min. 2.1 A, not included in the items supplied).
The 4 control LEDs 2 flash successively and will light up when
the battery is fully charged.
1 LED flashes
1 LED is lit, the second LED flashes
2 LEDs are lit, the third LED flashes
3 LEDs are lit, the fourth LED flashes
4 LEDs are lit
LED display Charging state
< 25 %
approx. 25 % – 50 %
approx. 50 % – 75 %
approx. 75 % – 99 %
100 %
