surface) and an error message that comes
on. Make sure, you operated the hob
correctly. If not the servicing by a service
technician or dealer will not be free of charge,
also during the warranty period. The
10. TECHNICAL DATA
10.1 Rating plate
Model I64AV423FB
Typ 61 B4A 01 AA
Induction 7.2 kW
Ser.Nr. .................
AEG
10.2 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
Left front 2300
Left rear 2300
Right front 1400
Right rear 1800
The power of the cooking zones can be
different in some small range from the data in
the table. It changes with the material and
dimensions of the cookware.
For optimal heat transfer and cooking results
use cookware with bottom diameter similar to
11. ENERGY EFFICIENCY
11.1 Product Information according to EU Ecodesign Regulation
Model identification
Type of hob
Number of cooking zones
Heating technology
information about guarantee period and
Authorised Service Centres are in the
guarantee booklet.
PNC 949 597 991 00
220 - 240 V / 400 V 2N, 50 - 60 Hz
Made in: Germany
7.2 kW
PowerBoost [W] PowerBoost
maximum dura‐
tion [min]
3200 10
3200 10
2500 4
2800 10
the size of the cooking zone (i.e. the
maximum cookware diameter value in the
table). Do not use cookware larger than the
diameter of the cooking zone.
Cookware diame‐
ter [mm]
125 - 210
125 - 210
125 - 145
145 - 180
I64AV423FB
Built-In Hob
4
Induction
