the right hand corner of the fuelbed (Fig 6). Particular care should be given after installation to ensure the receiver jack
is fully connected to ensure the product functions correctly (Fig 7).
COMMISSIONING/INITIAL PRODUCT START-UP
FILLING THE WATER TANK
Before powering on the product for the first time, ensure that a full water tank has been placed on the product. Open the
drawer and remove the water tank from its location on top of the sump (Fig 8) and open it by unscrewing the orange cap
(Fig 9). The tank should be filled with clean tap water only - Refer to WATER QUALITY & CLEANING for more details.
When the tank is replaced on top of the sump, it will take about one minute for the tank to empty into the sump. Allow the
sump to fill fully before switching on the product. Once filling is complete, the tank can be refilled and replaced on top
of the sump. This will allow for the maximum capacity of water to be stored in the product. Close the drawer when filled.
OPERATING THE PRODUCT
This section describes how to activate your fire using either the manual controls and remote control.
MAINS SWITCH
Open the drawer to access the control panel. The mains switch is located on the module and controls the electricity to
the appliance (Fig 10A).
Note: This switch must be in the 'ON' ( I ) position for each appliance to operate.
MANUAL CONTROLS
Manual controls are discretely hidden under the log on the right hand corner of the fuel bed. To access simply lift off the
log (Fig 6).
REMOTE CONTROL
The remote control is supplied with 2x CR2032 batteries already fitted. Pull both tabs from the rear cover to engage the
batteries (Fig 11) and allow remote operation.
Note: The tethered receiver must be fitted to the product for remote control operation.
PAIRING THE REMOTE CONTROL
The remote control has wireless Bluetooth technology and needs to be paired to the receiver. This can be done by
following the steps below.
1.
Open the drawer and press the rocker switch to the on (I) position.
2.
Press the button on the control panel (Fig 10B); the product will turn on.
3.
Press the button on the control panel (Fig 10B), the LED's will start to slowly blink on and off.
4.
Press the button on the remote control; the product LEDs will flash quickly five times and the product will then
automatically switch off. The remote control is now paired to the product and can be used to switch it back on.
TO REPLACE THE BATTERIES
1.
Remove battery cover of the remote control using a Philips screwdriver (Fig 12).
2.
Correctly install two 3 Volt (CR2032 or similar) battery in the battery holder with the + side facing up .
3.
Secure the battery cover using the previously removed screw.
Batteries must be recycled or disposed of properly.
Check with your Local Authority or Retailer for recycling advice in your area .
Frequency band(s) this product operates in: 2.4GHz
Maximum radio-frequency power transmitter in the frequency band(s) this product operates in: 8.23dBm
CREATING YOUR PERFECT OPTIMYST EFFECT
With Optimyst technology you can create a flame effect that is unique to you. First ensure the appliance is on by pressing
the main switch to I (Fig 10). To turn on the flames press the
the ENTER button to activate and use the
FLAME COLOUR: There are 6 colour themes to chose from. To adjust the flame colour, navigate to colour icon
the remote and press enter. Use
manual controls press the
TIP: Orange is the go to colour for a traditional authentic look, but when it is time for a celebration switch to the Prism
theme that cycles through a rainbow of colours. In summer time blue is both cooling and calm, whilst green always
draws attention at Holloween.
or buttons to navigate to the
or to toggle between options 1 to 6 flame themes and ENTER to select. On the
repeatedly to cycle through the colours.
button on the manual controls. If using the remote, press
icon and press ENTER to select.
