Technical Information,
Heat Output
Nominal Heat Output
Minimum Heat Output
Maximum Continuous Heat Output
Auxiliary Electricity Consumption
In Standby Mode
No room temperature control
INSTALLATION INSTRUCTIONS
This section describes how to install and set up your fire.
BEFORE YOU START:
•
Ensure that all packing items are removed (read any warning labels carefully) and retain all packing for possible
future use.
•
Before connecting the appliance, check that the supply voltage is the same as that stated on the appliance.
•
Ensure that the appliance is installed on a level surface.
•
Make sure the appliance is switched OFF for installation.
CONNECTIONS REQUIRED IN ADVANCE OF INSTALLATION
ELECTRICAL CONNECTION
Plug the fire into a 16amp 230/240 Volt outlet located within 1m of the product. Be sure to have access to the plug after
installation to allow for disconnection. Ensure that the supply cable exits at the back of the fire to suit your supply socket
location and is not trapped under the fire such that it might cause it to be damaged.
BUILDING THE PRODUCT SURROUND/ENCLOSURE
This product can be built into a wall, surround or structure. Please take note of the product dimensions (Fig.1) and build
your wall, surround or structure accordingly. Suitable clearance should be provided to allow the product to be installed
easily.
You are required to leave a minimum of 400mm from the base of the fuel bed to any shelf/enclosure above the product
(Fig 2). This will allow enough space above the product to allow the flame effect to form fully and not to be obstructed.
When determining a location for the product, ensure that the unit will not be susceptible to drafts, vents, ceiling fans and
other air currents. Similar to a candle, large movements of air will affect the unit's ability to create and maintain the flame
effect. If the desired location is susceptible to significant air movement, i.e. air vents, the different installation options
illustrated in (Fig 2) can be used.
VENTILATION
This product needs free ventilation from underneath to operate correctly (Fig 3). There are slots on the underside and
side walls of the product and along the drawer front to allow this free air through the product (Fig 2). The free ventilation
helps keep the electronic components cool and allows the mist to rise and leave the product. Please take note of the
requirement for ventilation around the product and ensure that vents are not blocked. If fitting into a surround/enclosure
ensure that there is a ventillation gap to allow a clear path for the air to get into the product (210cm², Fig 3).
INSTALLING THE PRODUCT INTO SURROUND/ENCLOSURE
Once your enclosure has been built to the required dimensions and the electrical connection has been installed, follow
the steps below to install your product.
1.
Sit the product on the constructed base, ensuring the cable is accessible and not caught under the product.
2.
Ensure the product is at the correct height to suit the installation and ensure it is adequately level.
3.
Once the product is at the correct height and is level, centre the product within the opening.
4.
With the product in its final position, unscrew the fuel bed and carefully lift off to remove (Fig 4). The fuelbed should
be lifted by holding the metal tray the logs are fixed on, not by lifting the top logs as this could damage them.
5.
Using fixing screw pack provided, screw fix the product into position through the fixing holes in the base to ensure
it can't tip over when the drawer is opened (Fig 5).
6.
Carefully place the fuelbed back in position, lifting by the metal tray and screw fix to secure.
7.
The power cord is on the back of the product. Please take note of this when constructing the surround/enclosure
(Fig 1).
MANUAL CONTROLS (TETHERED RECEIVER UNIT)
The product is fitted with manual controls on a tethered receiver unit, which must be connected to operate the product.
This also acts as the receiver unit for the remote control operation. The manual controls are located under the log on
Model No: JUN-RGB-EU, JUNXL-RGB-EU, CASL10P-RGB-EU
230V
P
0.24
Nom
P
0.24
min
P
0.24
max
-
-
P
0.46
Nom
5
240V
0.26
kW
0.26
kW
0.26
kW
-
-
0.48
W
