15. Maintenance
m ATTENTION!
Pull out the power plug before carrying out any mainte-
nance work on the equipment.
We recommend:
• The splitting wedge is a wearing part that needs to
be sharpened or replaced after wear.
• The combined gripping and controlling device must
remain smooth running. Lubricate with a few drops
of oil when necessary.
• Keep splitting wedge drive clean of dirt, wood shav-
ings, bark, etc.
• Lubricate slide rails with grease.
Check the oil level regularly.
An oil level that is too low will damage the oil pump
Regularly check hydraulic connections and screw con-
nections for leaks – retighten if necessary.
When must the oil be changed?
Change the oil after 150 working hours.
Oil change (fig. 17 - 20)
1.
Move the log splitter into the start position and pull
out the mains plug.
2.
Undo the oil drain screw with dipstick (8) and put it
to one side. (fig. 18)
3.
Turn the log splitter on the support leg side as
shown in fig. 19 over a 4 liter capacity container
to drain the hydraulic oil off. Recycle carefully! Dis-
pose of the waste oil in an environmentally friendly
manner!
4.
Turn your machine on the motor side as shown in
Fig. 20 to refill about 3,5 l fresh oil.
5.
Clean the oil drain screw with dipstick (8) and
screw it back in to the machine that is still in a ver-
tical position. Unscrew it again; there should be an
oil film between the two notches. (Fig. 17)
6.
Now screw the oil drain screw with dipstick back
in tightly. Afterwards start splitting without actually
splitting log several times.
7.
Check the oil level one last time and top up with a
little oil if required.
Dispose of the used oil in a correct manner at a
public collection facility. It is prohibited to drop
old oil on the ground or to mix it with waste.
We recommend oil from the HLP 32 range.
Connections and repairs
Connections and repairs of electrical equipment may
only be carried out by an electrician.
Please provide the following information in the
event of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Motor data - type plate
Service information
Please note that the following parts of this product are
subject to normal or natural wear and that the following
parts are therefore also required for use as consum-
ables.
Wear parts*: riving knife, hydraulic oil, riving bar guide
* Not necessarily included in the scope of delivery!
Spare parts and accessories can be obtained from our
service centre. To do this, scan the QR code on the
cover page.
16. Disposal and recycling
Notes for packaging
Notes on the electrical and electronic equipment
act [ElektroG]
Waste electrical and electronic equipment
does not belong in household waste, but
must be collected and disposed of sepa-
rately!
• Used batteries or rechargeable batteries that are not
installed permanently in the old appliance must be
removed non-destructively before disposal. Their
disposal is regulated by the battery law.
• Owners or users of electrical and electronic devices
are legally obliged to return them after use.
• The end user is responsible for deleting their per-
sonal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that
waste electrical and electronic equipment must not
be disposed of with household waste.
www.scheppach.com
The packaging materials are recy-
clable. Please dispose of packag-
ing in an environmentally friendly
manner.
GB | 29
