7 Assembling the Lawn Mower
2 3
4
1
► Plug the mains plug (6) into an easily accessi‐
ble socket (7).
The charger (3) will run a self-test. The
LED (4) will glow green for about 1 second
and red for about 1 second.
► Routing the connecting cord (5).
► Insert the battery (2) in the guides in the
charger (3) and press it home as far as stop.
The LED (4) glows green. The LEDs (1) glow
green and the battery (2) is being charged.
► When the LED (4) and the LEDs (1) on the
battery no longer light up: The battery (2) is
fully charged and can be removed from the
charger (3).
► If the charger (3) is no longer required: Dis‐
connect the mains plug (6) from the wall out‐
let (7).
6.3 Displaying the state of charge
1
► Depress the pushbutton (1).
The LEDs light up green for about 5 seconds
and indicate the state of charge.
► If the LED on the right flashes green: Charge
the battery.
6.4 LEDs on Battery
The LEDs can show the state of charge or mal‐
functions. The LEDs can glow or flash green or
red.
The state of charge is indicated when the LEDs
glow or flash green.
► If the LEDs glow or flash red: Troubleshooting,
19.1.
There is a malfunction in the mower or battery.
0478-131-9630-B
6.5
The LED indicates the operating status of the
7
6
charger.
If the LED glows green, the battery is being
charged.
► If the LED flashes red: Rectify the malfunction.
5
7
7.1
► switch the lawn mower off and remove the bat‐
► Place the lawn mower on a level surface.
► Press sleeve (1) into the bores in upper han‐
► Fit spring washers (3) with the convex side
80-100%
60-80%
40-60%
20-40%
0-20%
► Guide upper handlebar (2) into handlebar
► Push bolt (5) through the bores in handlebar
► Place nut (6) in the notch in handlebar
► Tighten bolt (5).
LED on Charger
Malfunction in charger.
Assembling the Lawn
Mower
Attaching the Handlebar
tery.
dlebar (2).
facing inwards onto sleeve (1).
bracket (4).
bracket (4) and the sleeve in upper handle‐
bar (2).
bracket (4).
English
