Table 4 Audio Inputs
A. Local PA (Use optional Model MSB-1 microphone)
Input Impedance 5 kΩ
Input Voltage 16 mV
B. Channel A / Channel B
Input Impedance 28.87 kΩ at 1 V
22.67 kΩ at 25 Vrms position
22.10 kΩ at 70 Vrms position
Input Voltage Selectable to be 1 V
70 V
Table 5 Audio Outputs
Output Impedance
Balanced Signal Line
Output Voltage Levels No Load
Balanced Signal Line at 70 V Position
Balanced Signal Line at 25 V Position
Balanced Signal Line at 1 V Position
Table 6 Remote Preset Activations Circuit
Type Dry contact closure
Line Impedance 1 kΩ max
Circuit Current 20 mA max (12 Vdc)
NOTE: It is recommended that the installer use shielded,
twisted pair wire in order to minimize any false activation
due to environmental noise.
Table 7 Remote Mic Activation Circuit (PTT)
Type Dry contact closure
Line Impedance 100 Ω max
Circuit Current 10 mA max (12 Vdc)
Table 8 Relay Contact Closure Outputs
Type Dry contact closure
Rating 15 A maximum current per zone
Table 9 Fuse
F1 Type GMC 2 A, 250 V
F2 Bussman-type GMT 4 A
Table 10 Physical
Weight 16 lb 8 oz (7.5 kg)
Dimensions (HxWxD) 3.5 x 17-3/8 x 14.25 in
(89 x 442 x 362 mm)
Case Material 14 GA aluminum
Federal Signal signaling.fedsig.com
(MAX)
rms
position
rms
, 25 V
rms rms
rms
27 Ω
70 V
rms
25 V
rms
1 V
rms
Agency Approvals
UL AND cUL Certifications
• UL 813, (AZJX) Commercial Audio and Radio
Equipment, Systems and accessories
• C22.2 No. 1-98, (AZJX7) Audio, Video, and Similar
Electronic Equipment
FCC
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
, or
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Unpacking the Device:
examine it for damage and verify the parts. If a part is
missing or damaged, do not attempt to install it; contact
Federal Signal Customer Support.
Installation
Mounting
The AR2000-M provides four holes for mounting in a
standard rack. It utilizes a space of 2 U.
Electrical Connections
SHOCK HAZARD: To avoid electrical shock and damage
to the device, do not attempt to connect wires when
power is on.
Terminal blocks are supplied on the AR2000-M for field
wiring. Strip 1/4" of insulation from the wiring leads.
Attach the appropriate wires to the corresponding
terminals. Tighten the screws to ensure that the wires are
firmly held in place. The terminals accept conductor sizes
22 to 12 AWG.
Signal Lines
The signal lines transfer the tone signals and verbal
messages from the AR2000-M to the selected zones
and their devices. In order to reduce the possibility of
cross-talk, hum, and static noise pick-up, the signal lines
must be twisted pair, shielded audio cable. Although
the majority of systems use 18 AWG shielded, twisted
pair audio cables, the size of the audio cable should be
adjusted to correspond to the level of audio being routed
in your application.
After unpacking the device,
3
