Technical Data
15.6 Remote Operation
Approved external control system
Sartorius FlexAct COM
®
Communication connection
Using a connection cable for remote operation
Type of connection cable for remote operation: Shielded 8-pin plug, M12, A coded,
screw assembly with M16 thread, 8 x 0 .25 mm
Input signals from remote control
Target value for mixing speed at 0 – 750 rpm
Target value for mixing speed at 1 rpm
Start mixing process: Relay status
Stop mixing process: Relay status
Output signals of the device in remote operation
Actual value for mixing speed at 0 – 750 rpm
Actual value for mixing speed at 1 rpm
Remote operation activated: Relay status
Remote operation deactivated (local operation): Relay status
Warning message or error message present: Relay status
No warning message or error message on the device: Relay status
15.7 Recipe Storage and Message Memory
Recipe storage
Number of recipes, max
Number of phases in the recipe, max .
Message memory
Number of saved messages (error messages, warning messages), max .
15.8 Materials
Device surfaces
Stainless steel
Glass bead blasted
Operating display: Foil coated with polyester foil
Castors: Polyamide
52 Operating Instructions
2
Flexsafe
® Pro Mixer Drive Unit
V 0 – 10
mV 13 .3
Closed
Open
mA 0 – 20
µA 21 .3
Closed
Open
Closed
Open
Unit Value
25
10
100
Unit Value
316L
Ra 1 .2
