PARTS & SCHEMATICS
PARTS LIST
No.
Specification
1
Rubber Fixer Strip
2
Kill Switch Cover
4
Rubber Plate
8
In-Feed Hopper
10
Seal Cover (Left)
11
In-Feed Damping Rubber
12
Engine (Recoil/Electric Start)
13
Engine Fixture Plate
14
Main-Frame
15
Spacer dia. 35 x dia. 45 x 10
17
Buckle
18
Seal Cover (Right)
19
Belt Inner Cover
20
Discharge Damping Rubber
21
Arch Plate
22
Front Wheel Frame
23
Front Wheel Rotation Frame
24
M10 Screw and Nut
25
M10 Locknut
26
Axle Cover
27
Bearing 6204
28
M24 x 1.5 Slot Nut
29
Tow Bar
30
Tow Hitch
31
Chain
32
Deflector
33
Discharge (Top Part)
34
Discharge (Middle Part)
35
Discharge (Bottom Part)
36
Spacer dia. 21 x dia. 25 x 95
37
Fore-Wheel Fixture
38
Wheel 4.10-4
39
Washer dia. 16 x dia. 26 x 3
40
Screw M16 x 12
30 | OPC566E man.
No.
Specification
41
Dust Cap
42
M24 x 1.5 Slotted Nut
46
Rear Wheel Axle
47
Bearing F207
48
Roller
49
Blade
51
Anvil
52
Anvil Fixture
53
Battery Fixture
54
Battery Box
55
Battery 12V20AH
56
Bearing Cover
61
V-Belt 17 x 1143
62
Engine Pulley
63
Roller Pulley
64
Belt Cover
66
Fore-Wheel Fixing Frame
67
Tire 4.8-8
68
Press Switch
69
Switch Base
Scan here to access the DK2 POWER
Parts Store or open your browser and go to
www.detailk2.com/shop-power-equipment-parts
Your Wood Chipper model is:
OPC566E
