Performances des ventilateurs de refoulement - hauteur
manométrique standard-débit d'air minimum
Pression statique
utile (Pa)
débit [m /h]
3
vitesse [t/min]
01
rendement
puissance él. abs.
[kW]
débit [m /h]
3
vitesse [t/min]
02
rendement
puissance él. abs.
[kW]
débit [m /h]
3
vitesse [t/min]
03
rendement
puissance él. abs.
[kW]
débit [m /h]
3
vitesse [t/min]
04
rendement
puissance él. abs.
[kW]
débit [m /h]
3
vitesse [t/min]
05
rendement
puissance él. abs.
[kW]
débit [m 3 /h]
vitesse [t/min]
06
rendement
puissance él. abs.
[kW]
débit [m 3 /h]
vitesse [t/min]
07
rendement
puissance él. abs.
[kW]
débit [m /h]
3
vitesse [t/min]
08
rendement
puissance él. abs.
[kW]
90 100 120 150 180
1800 1800 1800 1800 1800
1169 1 190 1232 1291 1349
62.8% 62.8% 62.7% 62.5% 62.1%
0.13 0.14 0.15 0.18 0.20
1800 1800 1800 1800 1800
1170 1191 1233 1293 1351
62.8% 62.8% 62.7% 62.5% 62.1%
0.13 0.14 0.15 0.18 0.20
2700 2700 2700 2700 2700
1436 1452 1485 1534 1582
55.7% 56.7% 58.2% 59.9% 60.9%
0.22 0.23 0.25 0.28 0.31
2700 2700 2700 2700 2700
1120 1139 1175 1227 1279
57.8% 58.2% 59.0% 59.6% 59.8%
0.21 0.22 0.25 0.28 0.32
4000 4000 4000 4000 4000
1376 1388 1416 1455 1495
43.1% 44.6% 46.9% 50.0% 52.3%
0.36 0.37 0.40 0.44 0.49
4000 4000 4000 4000 4000
997 1011 1037 1077 1116
56.5% 57.4% 59.2% 60.9% 62.2%
0.28 0.29 0.32 0.37 0.41
6500 6500 6500 6500 6500
1452 1460 1476 1502 1527
39.8% 41.1% 43.6% 46.7% 49.2%
0.73 0.75 0.79 0.86 0.92
6500 6500 6500 6500 6500
1051 1062 1082 1112 1142
53.3% 54.3% 56.1% 58.3% 59.8%
0.55 0.57 0.62 0.69 0.76
210 240 270 300 330
1800 1800 1800 1800 1800
1405 1457 1509 1560 1609
61.8% 61.4% 61.0% 60.5% 60.2%
0.23 0.26 0.28 0.31 0.34
1800 1800 1800 1800 1800
1406 1459 1511 1562 1609
61.7% 61.3% 60.9% 60.5% 60.2%
0.23 0.26 0.28 0.31 0.34
2700 2700 2700 2700 2700
1627 1673 1717 1760 1801
61.9% 62.2% 62.5% 62.6% 62.8%
0.34 0.38 0.41 0.45 0.48
2700 2700 2700 2700 2700
1328 1376 1420 1465 1508
59.8% 59.7% 59.6% 59.3% 58.9%
0.35 0.39 0.43 0.47 0.51
4000 4000 4000 4000 4000
1534 1573 1613 1650 1687
54.2% 55.6% 56.6% 57.5% 58.3%
0.53 0.58 0.63 0.68 0.72
4000 4000 4000 4000 4000
1155 1193 1231 1268 1304
62.7% 63.2% 63.3% 63.3% 63.2%
0.46 0.51 0.56 0.61 0.67
6500 6500 6500 6500 6500
1552 1577 1602 1627 1651
51.4% 53.3% 54.8% 56.3% 57.4%
0.99 1.06 1.12 1.19 1.26
6500 6500 6500 6500 6500
1171 1201 1231 1260 1289
61.1% 61.9% 62.2% 62.7% 62.8%
0.83 0.91 0.99 1.07 1.15
31
Manuel de sélection et d'installation
360 390 420 450 510
1800 1800 1800 1800 1800
1656 1702 1746 1791 1877
59.8% 59.6% 59.4% 59.1% 58.6%
0.36 0.39 0.42 0.44 0.50
1800 1800 1800 1800 1800
1656 1703 1748 1792 1877
59.9% 59.5% 59.3% 59.0% 58.7%
0.36 0.39 0.42 0.44 0.50
2700 2700 2700 2700 2700
1843 1884 1924 1963 2039
62.8% 62.6% 62.5% 62.4% 62.1%
0.52 0.55 0.59 0.63 0.70
2700 2700 2700 2700 2700
1549 1590 1629 1668 1742
58.5% 58.0% 57.7% 57.1% 56.2%
0.55 0.60 0.64 0.69 0.78
4000 4000 4000 4000 4000
1724 1761 1796 1831 1900
58.7% 59.1% 59.4% 59.7% 59.9%
0.78 0.83 0.88 0.93 1,04
4000 4000 4000 4000 4000
1340 1375 1410 1444 1510
63.0% 62.8% 62.5% 62.1% 61.4%
0.72 0.78 0.84 0.89 1.01
6500 6500 6500 6500 6500
1676 1702 1726 1750 1799
58.4% 59.1% 59.9% 60.5% 61.3%
1.33 1.41 1.48 1.56 1.71
6500 6500 6500 6500 6500
1318 1345 1374 1402 1456
62.9% 63.0% 62.8% 62.7% 62.4%
1.24 1.32 1.41 1.50 1.68
550 600
1800 1800
1930 1997
58.5% 58.3%
0.53 0.58
1800 1800
1932 1999
58.4% 58.2%
0.53 0.58
2700 2700
2089 2148
61.8% 61.6%
0.76 0.82
2700 2700
1787 1844
55.7% 54.9%
0.84 0.92
4000 4000
1944 1999
59.9% 59.8%
1.11 1.21
4000 4000
1553 1605
61.0% 60.4%
1.09 1.20
6500 6500
1830 1871
61.9% 62.2%
1.81 1.95
6500 6500
1491 1535
62.1% 61.6%
1.81 1.97
