Renfert SIMPLEX Mode D'emploi page 12

Question / Error / Problem
How does the print data get
from the PC to the printer?
en
Why is a WiFi connection not
recommended?
What frequency band is used
by the Simplex WiFi module?
Can acetone be used to clean
the print bed?
What grease should be used
to lubricate the printer?
Connectivity of the Renfert
CONNECT app and SIMPLEX
3D filament printer.
How many models can be
printed on average using one
reel?
Can the models be cleaned
using acetone?
Process for replacing fila-
ments.
Does every filament have an
expiry date and storage con-
ditions?
Is it possible to bond
SIMPLEX filament models?
Cause
• In the case of a poor WiFi connec-
tion, the connection between the PC
and the SIMPLEX may be interrupt-
ed with the result that it cannot be
ensured that SIMPLEX print can be
used securely and reliably.
- 4 -
Troubleshooting / Solution
• We generally recommend printing via USB flash
drive: the G-Codes are saved from the PC to the
USB flash drive. The USB flash drive must then be
inserted into the USB port of the printer.
• If the printer is located adjacent to the PC, it is pos-
sible to print using a USB cable: the USB flash drive
is not required. During printing, the connected com-
puter must not be shut down or switched to stand-
by / energy-saving mode.
• Printing via WiFi: Only recommended for WiFi net-
works with good coverage and few outages. The
USB flash drive must be inserted in the USB port.
The USB flash drive is used as an external storage
medium.
• If data transfer via WiFi is not stable, we recom-
mend printing using a USB flash drive.
• The WiFi module of the printer only operates at 2.4
Ghz.
• No, acetone would damage the Kapton. Corre-
sponding cleaning agents are listed in the IFU.
• Grease is not included in the scope of delivery of the
printer.
• Generally, PTFE lubrication grease should always
be used.
• The SIMPLEX printer and the CONNECT app can-
not communicate directly with each other due to
different software languages.
• No notifications (e.g., print stop) are sent via the
app.
• For news or software updates, please visit our web-
site at myRenfert.
• On average, 40 - 50 models depending on the size
and type of model.
• Over time, acetone degrades PLA. If briefly wiped
with acetone, models become matt.
• If TEMP1 or TEMP2 filament is used, the filament
must always be loaded or unloaded using TEMP2
settings.
• For more information, see Chapter 7.3 in the instruc-
tions for use.
• Our filament does not have an expiry date, but it
should be stored in a closed container and dark
location with silica gel in order to protect the filament
against damp.
• Yes
- using fast-acting adhesive:
Using fast-acting adhesive can cause white spots
to develop.
- Hot-melt adhesive:
Ensure that the resin begins to soften from
60 - 70 ºC. It must be ensured that the areas to be
bonded do not become too hot.
- or using 2-part adhesive
