3. Technical data
Feature
Power supply
Current consumption max.
Power consumption max.
Internal module dimensions
(L x W x D)
Outer rosette dimensions
(Ø x D)
Ambient temperature for
operation (standard version)
Ambient temperature for
operation (outdoor version)
Relative humidity
Protection class (indoor module)
Protection class (external rose
with sealed foil)
Protection class (outdoor
rosette for outdoor version and
exclusively with sealed foil)
Transponder technology
Low power wireless technology
Signalling
Approvals
Tested to
RFID frequency
Transmitter field strength /
(dbμA/m) @3m
Low Power Wireless Frequency
(BLE / Thread)
Radiated power (dBm)
Value
Tested and recommended by Häfele:
4x 1.5 V Mignon battery AA (LR6) alkaline
Type E91 Energizer industrial
(Häfele Cat. No.: 910.54.980)
0.3 A (6 V)
1.8 W
228 mm x 66 mm x 46 mm (with rotary knob / without lever handle)
52 mm x 10 mm
0 °C - +55 °C
Outdoor module: -20 °C – +60° C (*)
(*) Caution: It is essential to use the sealed rosette foil for installations
exposed to weathering. Otherwise there is a risk that the profile
cylinder will freeze and emergency opening may no longer be
possible.
Indoor module: 0 °C – +55 °C
10% to 95%, not condensed
IP 40
IP 54
IP 54
ISO15693, ISO14443:
Tag-it, MIFARE Classic EV1, MIFARE DESFire EV1/EV2/EV3
The transponders used for Dialock software applications must be
qualified and encoded by Häfele.
• Commissioning, configuration and key administration of access
points with a smartphone and the Häfele My Dialock Manager app
• Opening an access point via low power wireless with a digital end
device and a suitable app (e.g. Häfele Access Hotel)
1x LED red, 1x LED white, piezo signalling device
ANATEL, DIN EN 179 (only in conjunction with U-handles)
DIN 18273
13.56 MHz
- 9.18
2400 MHz – 2483.5 MHz
-1.87
