General
Dimensions
Weight
Material
Degree of contamination
Relative humidity
Ambient temperature for storage
min. ... max.
Ambient temperature during operation
min. ... max.
Max. number of valves
Max. height above sea level
Vibration resistance for EN 60068-2-6
wall mounting
Shock resistance for EN 60068-2-27 wall
mounting
Electrics
Degree of protection according to
EN 60529 / IEC 60529
Supply voltage
Valve supply voltage
Nominal current
Power supply connection type
Current consumption of the electron-
ics
Permissible ripple
Standards and directives complied with
Standard / directive Description
EMC directive Electromagnetic compatibility of electric products and electronic
2014/30/EU products
EN 60204-1 Safety of machinery – Electrical equipment of machines, Part 1: Gen-
eral requirements
EN 61000-6-2 Electromagnetic compatibility (EMC); part 6-2: Generic standards –
interference immunity for industrial environments
EN 61000-6-3 Electromagnetic compatibility (EMC); part 6-3: Generic standards –
Emission standard for equipment in residential environments
Communication interface
Communications protocol
Connections
Profinet Conformance Class
Output data volume
Input data volume
15 Spare parts
Information on spare parts can be found on the product page in the Emerson
store.
16 Accessories
Information on accessories can be found on the product page in the Emerson
store.
AVENTICS™ PROFINET-IO | 570088-BAL-AA | English
Specifications
45 mm x 97.2 mm x 27.25 mm
0.089 kg
Fiberglass reinforced polyamide
2
95 %, non-condensing
-25 ... 80 °C
-10 ... 50 °C
24 (48 coils)
2000 m
±0.35 mm displacement at 10 Hz ... 60 Hz,
5 g acceleration at 60 Hz ... 150 Hz
30 g with 18 ms duration,
3 shocks each direction
Specifications
IP65 when assembled
24 V DC ±25 %
24 V DC ±10 %
3 A
M12 A-coded, 4 pin or 5 pin
0.2 A
5 %
Specifications
PROFINET IO
Fieldbus connection X7E1 and X7E2
• Base, female, M12, 4-pin, D-coded
• 100 Mbit full duplex switch with 2 connections,
for connecting several PROFINET IO devices in
series
C
48 bits
112 bits
Description
Plug connector, CN2 series, male, M12x1, 4-pin, D-
coded, 180° straight cable outlet, for the fieldbus con-
nection X7E1/X7E2
• Max. wire cross-section: 0.14 mm² (AWG26)
• Ambient temperature: -25 °C ... 85 °C
• Nominal voltage: 48 V
Base, CN2 series, female, M12x1, 4-pin, A-coded, 180°
straight cable outlet, for the connection of the power
supply X1S
• Max. wire cross-section: 0.75 mm² (AWG19)
• Ambient temperature: -25 °C ... 90 °C
• Nominal voltage: 48 V
Base, CN2 series, female, M12x1, 4-pin, A-coded, 90°
angled cable outlet, for the connection of the power
supply X1S
• Max. wire cross-section: 0.75 mm² (AWG19)
• Ambient temperature: -25 °C ... 90 °C
• Nominal voltage: 48 V
Protective cap M12x1
Item no.
R419801401
8941054324
8941054424
1823312001
