b) Cleaning the outlet valve
If the spray pattern is poor, the outlet valve may need to be cleaned or replaced.
i
Problems can be avoided by cleaning and servicing the device properly.
1. Remove the high-pressure hose from the base unit using a wrench (17).
2. Loosen the screw (Allen wrench 2.5 mm) on the outlet valve (Fig. 26), but do not remove it.
3. Remove the outlet valve (Fig. 27, 1) from the base unit using a wrench (16).
4. Clean the outlet valve mount and the outlet valve thoroughly with a suitable cleaning solution or replace the outlet valve if
necessary.
5. Put the new or cleaned outlet valve back in.
6. Re-tighten the screw (Fig. 26).
Pos. Description
1 Spray gun assembly (incl. nozzle holder)
2 Nozzle holder
3 Sealing set
4 High-pressure hose, 15 m
5 HEA Filter Set (incl. filter red and filter white)
6 Pressure gauge
7 Door (1 pc.)
8 Telescopic handle
9 Suction hose and Return line
10 Clip (suction hose)
11 Clip (return line)
12 Return line
13 Clip (1 pc.)
14 Filter housing
15 Filter
16 Outlet valve
17 Repair kit for inlet valve
18 Inlet valve housing
Description
Nozzle 211 (20° spray angle, 0.011 inch nozzle diameter)
Nozzle 311 (30° spray angle, 0.011 inch nozzle diameter)
Nozzle 313 (30° spray angle, 0.013 inch nozzle diameter)
Nozzle 413 (40° spray angle, 0.013 inch nozzle diameter)
Nozzle 515 (50° spray angle, 0.015 inch nozzle diameter)
Nozzle 517 (50° spray angle, 0.017 inch nozzle diameter)
Nozzle 619 (60° spray angle, 0.019 inch nozzle diameter)
Filter, red (nozzle 211/311/313/413, 1 pack)
Filter, red (nozzle 211/311/313/413, 10 pack)
Filter, yellow (nozzle 515, 1 pack)
Filter, yellow (nozzle 515, 10 pack)
Filter, white (nozzle 517/619, 1 pack)
Filter, white (nozzle 517/619, 10 pack)
Gun extension (30 cm)
Gun extension (60 cm)
Easy Glide (118 ml)
Further information about the WAGNER range of products for renovating is available under www.wagner-group.com
Spare Parts List (Fig. 28)
Accessories (not included in the delivery)
GB
Order No.
0517101
0517200
0517900
0517802
0517202
0580402A
0580041Y
0580390
0580206A
9890222
0327226
0580208
0512390
0580154
0580155
0580072A
0580391
0580071A
Order No.
0517211
0517311
0517313
0517413
0517515
0517517
0517619
34383
97022
43235
97023
34377
97024
0517700
0517701
0508619
