D
Note:
The roller brush is not dishwasher-proof and not
waterproof.
Reinsert the square pin on the right-hand side
6
of the roller brush into the square hole in the
bearing block (1). Place the other end of the
roller brush in the recess (2).
D
Note:
You can ind the cleaning tool on the inside of the
dust container compartment cover (see section
'Emptying the dust container' in this chapter).
D
Note:
When you place the roller brush back into the
robot, make sure the ring is attached to the end
of the brush you insert last. If it is not, contact
the Philips Consumer Care Centre.
Place the roller brush retainer over the roller
7
brush (1) and press the sides of the retainer
home until the latch hooks lock into place
('click') (2).
7.6 Cleaning the sensors
Clean the obstacle detection sensors in the
1
bumper of the robot with a cotton bud.
Clean the loor detection sensors on the
2
bottom of the robot with a cotton bud.
7.7 Cleaning the front wheel
Push the latch hooks on either side of the
1
front wheel retainer to unlock them (1) and
lift the front wheel retainer off the robot (2).
Remove dust and dirt from the brush strip
2
on the retainer with the comb end of the
cleaning tool or with your ingers.
27
