ENGLISH
16
3 Key to Machine Parts (Page 2)
1
Control panel
2
Cup holder rest
3
Hot water/steam knob
4
Coffee brew unit
5
Water tank
6
Water recovery tray
7
Cup holder grill
8
Steam wand (Pannarello)
9
Power cord socket
10
Water temperature thermometer
11
ON/OFF button
12
"Machine on" light
13
"Coffee brew" button
14
"Temperature" light
15
"Rinsing" button
16
"Rinsing" light
17
"Steam" button
18
"Steam" light
19
"Descaling" light
20
"Alarm" light
21
Pressurized filter holder
22
Ground coffee measuring scoop
23
Ground coffee filter (single piece for 1 or 2 coffee(s))
24
Coffee pod filter adapter
25
Coffee pod filter
26
Power cord
27
"Intenza+" water filter (Optional)
4 Installation
For your own and other people safety, carefully follow
instructions in chapter "Important Safety Information".
4.1 Packaging
The original packaging has been designed and manufactured
to protect the machine during transport. We recommend
keeping the packaging material for possible future transport.
4.2 Installation Precautions
Do not move the machine by grabbing the cup
protection grilles.
Before installing the machine, read the following safety
precautions carefully:
• Place the machine in a safe place.
• Make sure children cannot play with the machine.
• Do not place the machine on hot surfaces or near open
flames.
The coffee machine is now ready to be connected to the electric
network.
4219-450-03851 MANUAL GAG. V2 RI8525 GGBF US 1-3L V2.indd 16
Note: we recommend washing the components
before using them for the first time and/or
after they have not been used for a certain period of
time.
4.3 Water tank
•
1
Remove the water tank (5).
•
2
Rinse it and fill it with fresh drinking water, making
sure that the (MAX) level indicated in the tank is not ex-
ceeded.
Fill the tank only with fresh, non-sparkling,
drinking water. Hot water or any other liquid
may damage the tank. Do not operate the machine
when the water level in the tank is below the MIN
threshold. Make sure there is enough water in the
water tank.
• Insert the water tank back into its seat in the coffee ma-
chine and make sure that it locks into place - its profile
should adhere to that of the coffee machine.
Note: the water level can be checked looking
through the window on the front side of the
tank.
4.4 Machine Connection
Electric power may be very dangerous! It is
therefore necessary to strictly follow the safety
regulations. Do not use faulty power cords. Faulty cords
and plugs must be replaced immediately by Authorised
Service Centres.
The voltage of the appliance has been pre-set by the
manufacturer. Check that the voltage matches the indication
on the data plate at the bottom of the appliance.
3A
•
Insert the plug into the socket on the back of the ma-
chine.
3B
•
Insert the other end of the plug into a wall socket with
suitable power voltage.
4.5 First Use
At first start-up, the coffee machine circuit must be primed.
4
Press the ON/OFF button (11): the "
and the "
" (14), " " (20) and " " (18) lights blink,
prompting the user to prime the circuit.
5
Place a container under the steam wand (Pannarello).
Open the "hot water/steam" knob (3) by turning it clock-
wise. The pump is activated automatically. Wait until
" light (12) turns on
03/09/2020 10:16:33
