ENGLISH
OPERATING INSTRUCTIONS
FINDING CIRCUIT BREAKERS
Insert the transmitter
into the electrical outlet and note the Wiring
1
Condition
&
. If the transmitter indicates that the outlet is
6
7
energized and correctly wired, prepare to scan the breakers in the
breaker panel with the receiver
If the tester indicates that the outlet is not wired correctly,
cease testing and consult a qualifi ed electrician.
Power ON the receiver. Before approaching the electrical panel, push
the Power On/Off/Reset button
the receiver so that the sensing tip
breakers in the panel. Slowly scan all breakers in the panel once, ignoring
any audible or visual indications as the receiver is learning the panel.
Scan all breakers a second time. When the breaker connected to
the circuit with the transmitter is approached, the frequency of the
audible beeps will increase. When located, the audible beep will sound
continuously, the circuit status indicator will illuminate red
green indicator in the sensing tip
correct breaker has been found.
NOTE: Resetting the receiver erases prior scanning data stored from
a previously 'learned' panel. Always reset the receiver away from
the electrical panel to ensure that electrical signals are not being
sensed during the reset operation.
6
.
2
once to reset the receiver. Position
3
is oriented perpendicular to the
5
9
will turn off, indicating that the
4
CONNECTING TO OTHER FIXTURES USING OPTIONAL ACCESSORIES
(CAT. NO. 69411)
LIGHT SOCKET FIXTURES
Screw the light fixture adapter into an empty light socket. Connect the
transmitter
1
fixture adapter. The indicators on the transmitter will communicate an
open ground wiring condition if the light socket is energized. Follow
the instructions in the FINDING CIRCUIT BREAKERS section to find the
correct circuit breaker.
, and the
Light Fixture
Adapter
BARE WIRES
The transmitter may be connected to bare wires using the outlet-to-
alligator clips wire adapter. Carefully attach the alligator clips the correct
wires. Insert transmitter into the outlet on the wire adapter. The indicators
on the transmitter will communicate an open ground wiring condition if
the wires are energized. Follow the instructions in the FINDING CIRCUIT
BREAKERS section to find the correct circuit breaker.
Exercise extreme caution when working around energized
bare wires.
OPERATING INSTRUCTIONS
to the 3-to-2 prong adapter, and connect this to the light
3-to-2 prong
adapter
Transmitter
1
7
