AMR PULSE W-Mbus- Mode d'emploi / User guide version V1.2
2.3. Electronic board
2.4. Technical Specifications
2.4.1 General characteristics
Parameters
Power supply voltage
Power supply
Operating temperature
Dimensions
Case
Radio standards
2.4.2 Product input tolerance characteristics
Parameters
Min. pulse width
Max. pulse frequency
Max current (open collector version)
Input resistance (dry contact version)
Max. voltage
2.4.3 Battery life
Conditions of use
Product storage before use:
1 year maximum.
Calculations carried out at
a temperature of 20°C
2.4.4 Radio characteristics
Mode
Radiated RF power
Wireless M-Bus T1
14dBm (25mW)
Wireless M-Bus R1
14dBm (25mW)
Wireless M-Bus S1
14dBm (25mW)
Wireless M-Bus C1
14dBm (25mW)
2.4.5 Operating modes
AMR PULSE has three states (modes) of operation.
•
STANDBY: this is the mode in which you receive your product (no transmission of radio frames).
•
OPERATION: this is the mode in which AMR PULSE transmits frames periodically. To switch to this mode of operation, you need to activate
the product with a magnet (see §3.6 Product start-up).
•
CONFIGURATION : this is the mode to which the product switches if it is already in operating mode and you place the magnet on the
product once more. The product automatically returns to operating mode after 4 min. This operating mode must be used with the dedicated
configuration software (available shortly).
Value
3.6 V nominal
Integrated Li-SOCl2 battery (radio management and querying of meters)
-25°C / +70°C
105 x 50 x 27mm
IP 67
EN 300-220, EN 301-489, EN 60950, EN 13757-3 and EN 13757-4
Value
8ms
33Hz
1mA
1kOhm
3.6V
Transmission frequency
10 sec
10 sec
10 min
10 min
12 h
12 h
Radio bandwidth
100 kbps
4.8 kbps
32 kbps
100 kbps
Number of meters
T Mode battery life
1
2
1
2
1
2
Range (with meter connected)
up to 600m
up to 800m
up to 800m
up to 600m
12 years
12 years
12 years
12 years
+12 years
+12 years
Page
32
of 44
