Etac / Swift Mobile Tilt Motor / www.etac.com
Charging the battery
The product must be dry and in a dry environment when
managing the battery.
J1. Take the battery out of the control box and place it in the C3
charger.
When the battery is located in the charger the green light starts
to flash until it is fully charged, at which time the light remains
constantly green.
Charging the battery
• The battery must be charged fully before the product is used for
the first time.
• When starting to use the product the battery must be charged
once a day or more frequently if necessary.
• When the product is not in use for a prolonged period the bat-
tery must be charged once a month.
• When fitting the battery make sure that the contact surfaces in
the battery and control box are clean and dry. If a beep is heard
the battery is fitted correctly and the chair is ready for use. If
there are two buzzing sounds followed by one beep, the control
box is in calibration mode and calibration must be completed
before further use.
• If the battery is hot after a charge or the chair is overloaded
when in use, the battery's overheating protection may be trig-
gered. Remove the battery and allow it to cool down for about
30 minutes.
• If the battery is taken out of the control box, wait at least one
minute before fitting a new battery.
• It is not permitted to use the chair without a battery in the
control box.
Motor
K1. Handset (Protection against water in line with IP 65), included.
K2. Charger, included
K3. Actuator (Protection against water in line with IP 66)
K4. Battery (Protection against water in line with IP 65)
K5. Control unit (Protection against water in line with IP 65)
Make sure the battery, actuator and the handset are connected
properly to the control unit.
Calibrating the actuators
L1. Both the up and down buttons are pressed simultaneously
until a beep followed by two buzzing sounds is heard (about
10-15 seconds). The control box is now in calibration mode.
L2. Calibration is carried out by holding the back button in until
both actuators stop in the end position. Keep the button
pressed in for an extra couple of seconds. The chair is now
calibrated and can be used.
All manuals and user guides at all-guides.com
English
See Figure J
Item list:
See Figure K
See Figure L
10
Fault-finding chart
Faults Possible cause
A signal is heard
The battery is almost
when using
flat
chair
The cables may not
If tilting does
be connected or the
not work
battery is flat.
The actuators
If tilting does
may need to be
not work
calibrated.
If tilting does The battery is
not work overheated.
Accessories
= Standard, = Accessory
Accessories
M1. Leg and calf rest, angle-variable
M2.
Footrest
M3. Commode pan
M4.
Pan-holder attachments
Attachments for low pan-holder
M5.
mounting
M6. Commode pan holders
M7. Bucket holders
M8. Splash guard
M9. Comfort seat
M10. Seat cover
M11. Anti-tip stabilisers including bracket
M12. Anti-tip stabilisers excluding bracket
M13. Headrest and bracket
M14. Crossbar 605 mm
M15. Heel straps
M16. Chest belt
M17. Positioning belt
M18. Hemiplegic armrest
M19. Armrest lock
M20.
Angle adj. footrest
M21. Soft back pad
M22.
Tilter
M23. Widening kit
Solution
Charge the battery
Insert the cables,
charge the battery.
Calibrate the
actuators.
Remove the battery
and allow it to cool
down for at least
30 minutes.
See Figure M
Item no.
8020 9437
8020 9443
8020 9254
8020 9435
8020 9259
8020 9257
8020 9258
8020 9430
8020 9433
8020 9434
8020 9459
8020 9438
8020 9447
8030 3034
8020 9432
8020 9442
8020 9440
8020 9035
8020 9445
8020 9446
8020 9448
8020 9449
8020 9444
