4.2 Scope of delivery

Cross-check scope of delivery with delivery note

5. Transport, packaging and storage

5.1 Transport
Check instrument for any damage that may have been caused by
transport. Obvious damage must be reported immediately.
5.2 Packaging
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during trans-
port (e.g. change in installation site, sending for repair).
WIKA operating instructions model 32
Legend:
1
2
3a
3a "Straight" + "135° angle" thermowell stem
3b "90° angle" thermowell stem
4a "Straight" + "135° angle" counter nut
4b "90° angle" retainer screw
3b
Housing with measuring range
Thermometer insert with temperature
scale and indicator fluid
