6. Operation
Install the equipment on a solid and level
surface.
Remove the ventilation screw (8).
Unscrew the coarse filter screw (7) and remove
the coarse filter (9) together with the non-return
valve (10) as shown in Figure 2. Now you can fill
the pump housing with water via the coarse filter
screw (7). Filling the intake line accelerates the
intake process.
Assemble in reverse order.
Open the discharge line.
Connect the mains cable.
Switch on the equipment with the power switch
(3) - water can be suctioned in for up to
5 minutes (maximum suction height).
The equipment will shut down when the cut-out
pressure of 3 bar is reached.
After a loss of pressure due to water
consumption the equipment will cut in again
automatically (cut-in pressure approx. 1.5 bar).
After finishing the work, switch off the
equipment with the power switch (3).

7. Replacing the power cable

If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
8. Cleaning, maintenance and
ordering of spare parts
The equipment is almost completely maintenance
free. In order to ensure a long service life, however,
we recommend that you regularly check and care
for the product.
Important!
The equipment must be disconnected from the
power supply (pull the power plug) prior to
performing any maintenance.
8.1 Servicing
If the equipment becomes clogged, connect the
discharge line to the water line and disconnect
the suction hose. Open the water line. Switch on
the equipment several times for approx.
two seconds. This should resolve the majority of
clog-related problems.
24.07.2008 8:49 Uhr Seite 11
Inside the pressure tank is an expandable water
sack and an air compartment whose maximum
pressure should lie at approx. 1.3 bar. Pumping
water into the water sack causes the sack to
expand so that the pressure in the air
compartment rises to switch-off level. If the air
pressure is too low, you should raise it. To do
so, unscrew the plastic lid from the tank and top
up the pressure to the correct level using a tyre
pump with meter at the valve.
Important: Be sure to completely empty the
water bag first using the water drain screw
(5).
Replacing the mains cable: Important:
Disconnect the equipment from the power
supply! A defective mains cable may only be
replaced by a qualified electrician.
There are no parts inside the equipment which
require additional maintenance.
8.2 Cleaning the coarse filter insert
Clean the coarse filter insert at regular intervals,
and replace it if necessary.
Remove the coarse filter screw (7) and coarse
filter (9) together with the non-return valve (10)
(Figure 2).
Disassemble the coarse filter insert as shown in
figure 3.
Do not use abrasive cleaning agents or petrol to
clean the coarse filter and the non-return valve.
Clean the coarse filter and the non-return valve
by tapping them on a flat surface. In cases of
stubborn dirt, first clean with soapy water, then
rinse with clear water and air-dry.
Assemble in reverse order.
8.3 Storage
If the pump is not going to be used for a long
time or has to be removed for the winter
months, rinse it out with water, empty it
completely and allow it to dry.
The equipment must be completely drained
before it is subjected to frost.
After long stoppages, make sure the rotor turns
correctly by briefly switching the pump on and
off.

8.4 Ordering replacement parts:

Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
