5.3 Typical arrangement
NOTE
The factory supplies only the heat pump. All other components, including a bypass if necessary, must be
provided by the user or the installer.
ATTENTION:
In order to heat the water in the pool (or hot tub), the filtration pump must be running so the water
is circulating through the heat pump. The heat pump will not start up if the water is not circulating.
5. Location and
5. 5. Location Location and and
This arrangement is only an illustrative example.
connection
connection connection
- 22 -
