Fuel Conversion/Gas Connections

LP Vapor Installation (typical)

A
NG BTU = ft
Megajoules = m
A.
B.
C.
D.
E.
F.
G.
H.
I.
22
B
F
G H
3
/h X 2500
3
/h X 93.15
BTU and Pressure Decal
Check Distance with Gas Provider
Primary Fuel Pressure Regulator Per LP Provider
Manual Shutoff Valve
Secondary Fuel Pressure Regulator
Flexible Fuel Line
Sediment Trap
Accessory Valve with Manometer Port
Size fuel tank large enough to provide required BTUs for generator and ALL
connected appliance loads. Be sure to correct for weather evaporation.
Figure 5-6. LP Vapor Installation (typical)
B
D
E
Owner's Manual for 60 Hz Synergy Generator™
C
I
000619b
