8
MAINTENANCE &
LUBRICATION
8.2
LUBRICATION
Read the safety instructions
Before using the machine for the first
time lubricate all points.
For recommended lubricants see section 8.1.
Should the number of working hours that the
machine is in use during the indicated period exceed
the number quoted in brackets, then use the
recommended 'working hour' guide as the lubrication
schedule.
8.2.1 ENGINE
Daily (Every 8 working hours)
Clean the sump filler cap and surrounding area.
Check level of oil in the sump. Remove dipstick plug
(B) from either side of crankcase and check that the
oil is up to the correct level.
Maximum oil level: To top of filler hole threads.
Minimum oil level: To bottom of dipstick.
Top up with recommended oil if necessary.
FIRST 5 AND EVERY 50 WORKING HOURS
DRAIN ENGINE OIL
(a).
After warming up the engine remove the drain
plug (A) and drain all oil from the sump. Clean
the plug and replace.
(b).
Refill the sump with the recommeded oil
through the dipstick/filler plug hole (B) up to
the correct level.
(c).
Replace filler plug (B) after filling.
NOTE: Ensure machine is on level ground when
checking oil level.
GB-30
All manuals and user guides at all-guides.com
SAFETY, OPERATORS & MAINTENANCE MANUAL
B
Use gloves when working with engine oil. If you
Copyright Briggs & Stratton Corp. Used with Permission.
Contact with engine oil can damage your skin.
come in contact with engine oil, wash it off
immediately.
Dispose of used engine oil in accordance with
local regulations
A
