TECHNICAL CHARACTERISTICS

CHARACTERISTICS OF THE SYSTEM
TECHNICAL DATA
Dosage in %
Dosage as a ratio
Operating flowrate
Operating pressure
Flowrate of injection of concentrated product
Maximum operating temperature
Average displacement of hydraulic motor
(every 2 piston clicks)
Inlet and outlet (NPT/BSP male gas)
MONITORING MODULE ELECTRIC CHARACTERISTICS
Device class
Device group
Power supply voltage
Maximum current consumption
Frequency [Hz]
Monitoring module box protection class
Monitoring module box insulation class
Power supply cable
(sector adaptor)
Protection
Batteries
Dimension of the packaging
Weight of the package
1 DOSATRON proportional hydraulic dosing device fitted with an flexible blade switch sensor/
1 wall-fitted dosing device support with monitoring subassembly/1 water meter/1 suction pipe/
1 strainer/1 "level detector" pipe/1 pipe guide/1 test tube for diagnosis/1 startup manual
class A
group 1
12-24Vdc, 80mA
Power 6W, i.e. 12V-500mA
See power supply
IP65
Class III equipment
Brand: Emerson or Artesyn embedded technology
Model: DA12-120EU-M
Characteristics: 220V A.C.50-60 Hz
Cable length: 1.5 m
IP65
This device contains a CR2032-type lithium battery (to
safeguard the RTC) .
When the general power supply is cut off, this device is
also fitted with a 9V - 6LR61 backup battery (autonomy
6 hours).
DIMENSION AND WEIGHT OF THE PACKAGE
53x35x18 cm
4,52 kg
COMPOSITION OF THE PACKAGE
©
DOSATRON INTERNATIONAL S.A.S. / 5
©
DOSATRON INTERNATIONAL S.A.S. / 41
METRIC UNIT
MIN
1
1:100
10 L/H
0,3 Bar
0,1 L/H
0,43 L
Ø 20 x 27 mm (3/4˝)
MAX
5
1:20
2500 L/H
6 Bar
125 L/H
40°C
