Endress+Hauser Proline Promag W 400 Information Technique page 50

50
DN A
[mm] [mm]
200 199
250 199
300 199
Dimension E
EN (DIN)
DN PN 10 PN 16
[mm] [mm] [mm]
25 – –
32 – –
40 – –
50 – –
65 – 185
80 – 200
100 – 220
125 – 250
150 – 285
200 340 340
250 395 405
300 445 460
Dimension H
EN (DIN)
DN PN 10 PN 16
[mm] [mm] [mm]
25 – –
32 – –
40 – –
50 – –
65 – 337
80 – 349
100 – 372
125 – 400
150 – 439
200 492 492
250 553 558
300 603 610
B C
[mm] [mm]
119 80
119 80
119 80
ASME
PN 25 PN 40 Class
150
[mm] [mm] [mm] [mm]
– 140 140
– 140 –
– 150 140
– 165 153
– 185 –
– 200 191
– 325 229
– 270 –
– 300 280
360 – 343
425 – 407
485 – 483
ASME
PN 25 PN 40 Class
150
[mm] [mm] [mm] [mm]
– 302 302
– 302 –
– 307 302
– 315 309
– 337 –
– 349 345
– 425 377
– 410 –
– 446 436
502 – 494
568 – 559
623 – 622
Proline Promag W 400
D F
[mm] [mm]
167 350
167 450
167 500
AS
Class Table E PN 16
300
[mm] [mm] [mm]
140 140 –
– – –
155 – –
165 150 150
– – –
210 185 185
254 215 215
– – –
318 280 280
– 335 335
– 405 405
– 455 455
AS
Class Table E PN 16
300
[mm] [mm] [mm]
302 302 –
– – –
310 – –
315 307 307
– – –
354 342 342
389 370 370
– – –
455 436 436
– 490 490
– 558 558
– 608 608
Endress+Hauser
G
[mm]
322
355
380
JIS
10K 20K
[mm]
140 140
140 140
140 140
155 155
175 175
185 200
210 225
250 270
280 305
330 350
400 430
445 480
JIS
10K 20K
[mm]
302 302
302 302
302 302
310 310
332 332
342 349
367 375
400 410
436 449
487 497
555 570
603 620
