English
► Press the button [2.1] to switch the laser on
or off. If the machine is not in use for 30 mi­
nutes, the laser will automatically switch it­
self off and must be switched on again.
9

Working with the power tool

WARNING
Flying tool parts/workpiece parts
Risk of injury
► Wear protective goggles.
► Ensure that no other persons are close to
the machine while it is being used.
► Always clamp workpieces tightly.
► The clamps must be fully laid out.
WARNING
The pendulum guard does not close
Risk of injury
► Stop the sawing process.
► Unplug the mains cable and remove the
wood waste. If the pendulum guard is dam­
aged, replace it.
WARNING
Risk of injury
► Observe the following instructions:
– Correct working position:
– At the front on the side of the operator;
– Head-on to the saw;
– Beside the line of cut.
– During operation, always hold the power
tool tightly by the handle [1–1] in your op­
erating hand. Always keep your free hand
outside of the hazardous area.
– Always use and fix extension table [1.8]
during operation (see chapter 8.5).
– Only guide the power tool towards the
workpiece when it is switched on.
– Adjust the feed speed in order to prevent
the machine from overloading and to pre­
vent the plastic from melting if you are cut­
ting plastics.
– Do not work on the power tool if its elec­
tronics are defective as this may lead to ex­
cessive speeds. You can tell if the electron­
ics are defective if there is no smooth start-
up, if it is not possible to regulate the speed
and in the event of generation of smoke or
the smell of burning from the machine.
18
– Before beginning work, ensure that the saw
blade cannot touch the stop rulers, work­
piece clamp, fastening clamps or other ma­
chine parts.
Always disconnect the mains plug from
the socket when the power tool is not in
use. This optimises the service life of the
electronics.
9.1

Workpiece dimensions

Maximum workpiece dimensions without ex­
tension using accessory parts
Mitre angles
according to
scale, horizon­
tal/vertical
0°/0° 88 × 305
45°/0° 88 × 215
0°/45° right 35 × 305
0°/45° left 55 × 305 2-3/16" × 12-1/64"
45°/45° right 35 × 215
45°/45° left 55 × 215
Maximum workpiece dimensions when instal­
ling together with the KA-KS 120
The maximum height and width of the work­
piece do not change if accessory parts are in­
stalled.
Accessory part used Length
KA-KS 120 (one
side)
KA-KS 120 (both
sides)
Long workpieces
Provide extra support for any workpieces that
protrude over the sawing surface:
► Adjust the extension table (see section 8.5).
► If the workpiece still protrudes, retract the
extension table and install the KA-KS 120
trimming attachment (see section 9.1).
► Use additional clamps to secure the work­
piece.
Thin workpieces
During sawing, thin workpieces may wobble or
break.
► During sawing, thin workpieces may wobble
or break.
Height x width
[mm]
3-1/2 × 12-1/64"
3-1/2 × 8-1/2"
1-3/8" × 12-1/64"
1-3/8" × 8-1/2"
2-3/16" × 8-1/2"
Up to 94-1/2"(2400 mm)
Up to 189"(4800 mm)
"
