Cameo FLAT PRO SPOTIX Manuel D'utilisation page 12

OPERATION:
METEOR
In the Meteor mode, a pixel control sequence retrieves successive colours
(pixel control = colour LEDs R, G and B of every single COB TRI LEDs are
controlled separately). The speed of the program is adjustable separately
and a stroboscope effect can also be activated.
Press the MODE button until "Meteor" appears in the upper line of the
display. Now, press ENTER until the cursor appears in the lower line of the
display, and then select the rate (SPEED) using the UP and DOWN buttons,
for the colour sequence from 00 to 99.
Confirm with ENTER. The indicator in the bottom line of the display changes
to "FLASH:xx". The cursor will appear in the bottom line at the same
time and you can activate the stroboscope effect using the UP and DOWN
buttons and adjust the strobe frequency from 00 to 99 (FLASH:00 = strobe
deactivated, FLASH:01 = approx. 1 Hz, FLASH:99 = approx. 20 Hz). Confirm
with ENTER.
Meteor
Stroboscope
FLOW
In the Flow mode, a pixel control sequence retrieves successive colours
(pixel control = colour LEDs R, G and B of every single COB TRI LEDs are
controlled separately). The speed of the program is adjustable separately
and a stroboscope effect can also be activated.
Press the MODE button until "Flow" appears in the upper line of the display.
Now, press ENTER until the cursor appears in the lower line of the display,
and then select the rate (SPEED) using the UP and DOWN buttons, for the
colour sequence from 00 to 99.
Confirm with ENTER. The indicator in the bottom line of the display changes
to "FLASH:xx". The cursor will appear in the bottom line at the same
time and you can activate the stroboscope effect using the UP and DOWN
buttons and adjust the strobe frequency from 00 to 99 (FLASH:00 = strobe
deactivated, FLASH:01 = approx. 1 Hz, FLASH:99 = approx. 20 Hz). Confirm
with ENTER.
Flow
Stroboscope
12
Speed SPEED: 00-99
Speed FLASH: 00-99
Speed SPEED: 00-99
Speed FLASH: 00-99
