OPERATION:
NOTE:
When the projector is properly connected to the mains, the following information
appears successively in the display during the startup process: "Software Update,
Please Wait..." (for service purposes only), the software version "SOFTWARE
V1.xx" and "WELCOME TO cameo". After this operation, the projector is ready for
use and changes to the mode that was previously selected.
STATIC COLOUR (STATIC)
This mode offers the ability to separately adjust the intensity for each of the 3 LED
groups and to generate an unlimited number of different colours (colour mixing).
Press the MODE button repeatedly until "STATIC" appears in the upper line of the
display. By repeatedly pressing the ENTER button, select the LED group for which
you want to change the brightness level (please note the cursor in the display,
Rxx = red, Gxx = green, Bxx = blue). Now you can set the intensity of the selected
light from 00 to 99 using the UP and DOWN buttons (example: R00 = red at 0%,
i.e. out. R99 = red at 100%, i.e. maximum brightness).
Adjust the flash frequency of the strobe effect by pressing ENTER repeatedly until
the cursor shows "Fxx". Now you can activate the strobe effect using the UP and
DOWN buttons and set the flash frequency from 00 to 99 (F00 = strobe effect
deactivated, F01 = approx. 1 Hz, F99 = approx. 20 Hz). Confirm with ENTER.
Red
Green
Blue
Stroboscope
COLOUR MACROS (MACRO)
In this mode, one of the 3 basic colours of the projector or one of the 4 different
mixed colours can be selected as a preset.
Press the MODE button repeatedly until "MACRO"
appears in the upper line of the display. Now press ENTER and then select one of
the 7 colour presets using the UP and DOWN buttons. Confirm with ENTER.
MACRO 01
MACRO 02
MACRO 03
MACRO 04
MACRO 05
MACRO 06
MACRO 07
10
Intensity R00 - R99
Intensity G00 - G99
Intensity B00 - B99
Speed F00 - F99
Red
Green
Blue
Yellow
Magenta
Cyan
White
