1/2" or thicker
Sole Plate tapped
for hold down bolts
Anchor
Bolts
Pump and Motor
Base
Shims
Concrete
Foundation
BE839
Installation

Pump Foundation

Typical Installations

Pump or
Motor Frame
Concrete Foundation
Shims
for alignment
Pump or
Motor Frame
Steel
Channel
Grout
Tack
Weld
Concrete
Foundation
• There are several types of permanent pump/
foundation installations in use. Those pictured above
are typical.
• If grout is used, top of concrete should be left rough
to provide a good bonding surface.
• Foundation should slope away from pump to prevent
liquid from pooling.
Anchor
Bolt
Wedges
Various Heights
Grout
Dam
1300 1094
