Replacement Parts Diagram - AirKing AKF80LS Manuel D'utilisation

3
4
34
33
# Qty. Description
1 1 Fan Housing
2 4 Mounting Rails
3 1 External Wire Cover
4 1 Screw
5 3 Screw
6 1 Gasket - Collar
7 1 Metal Collar
8 2 Damper
9 2 Bushing
10 1 Rod
11 1 Spring
12 1 Light Harness
13 1 Internal Wire Cover
14 1 Screw
15 1 Motor Cap Harness - AKF80LS
1 Motor Cap Harness - AKF100LS
16 1 Screw
17 7 Blower Screws
18 1 Motor Plate
19 1 Venturi
210572203 Rev. B 3-08

REPLACEMENT PARTS DIAGRAM

1
2
38
39
32
28
30
29
31
24
36
35
Replacement Part #
5S1202033
5S1299002
5S1202007
5S1999010
5S1999010
5S1202029
5S5202002
5S5202006
5S5202003
5S5202005
5S5202004
5S1202088
5S1202089
5S1999010
5S2202007
5S2202012
5S1999009
5S2202004
5S2202005
5S2202006
2
15
17
13
18
19
37
20
24
27
26
25
#
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
www.airkinglimited.com
6
7
16
14
12
23
22
21
Qty. Description
1 Reflector Support Bracket
1 Blower Wheel
2 Screw
1 Motor
5 Screw
1 26 Watt Lamp Holder
1 Light Reflector
1 Bushing
1 Clip
1 Ballast Mounting Bracket
2 Screw
1 Glass Lens
1 Grill
4 Lens Clips
2 Grill Springs
1 Reflector/Ballast/Ground
1 26 Watt Ballast Harness
1 Outlet Gasket
1 #10 Ground Screw
1 14 ga Ground Wire
5
11
8
10
9
Replacement Part #
5S1202036
5S2202003
5S2202002
5S2202001
5S1202037
5S1202090
5S1202015
5S1202018
5S1202017
5S1202091
5S1202040
5S5202001
5S1202020
5S1202021
5S1202092
5S1202093
5S1202042
5S1202043
5S1999002
5S1999003
6 of 12
